Introduction to Honeywell 05701-A-0351
05701-A-0351 Product Introduction
Honeywell 05701-A-0351 is a high-performance single-channel analytical control card belonging to Honeywell’s Series 57 product line. It is specifically engineered for industrial automation and process monitoring systems, serving as a critical interface for precise measurement and control of process parameters such as temperature, pressure, and flow. This module integrates infrared detection technology, enabling reliable detection of combustible, toxic, and inert gases, making it suitable for gas monitoring applications in hazardous industrial environments. With flexible input/output configuration capabilities, it supports 0-10V or 4-20mA analog signals and additional digital I/O channels, facilitating seamless connection with various field sensors and actuators. Its rugged industrial-grade construction and IP65 protection rating ensure stable operation under harsh conditions involving extreme temperatures, humidity, dust, and electromagnetic interference.
05701-A-0351 Technical Specifications
-
Product Model: 05701-A-0351
-
Product Type: Single-Channel Analytical Control Card (Honeywell Series 57)
-
Core Functions: Single-channel process parameter control and monitoring; Infrared gas detection (combustible, toxic, inert gases); Multi-type signal processing (analog/digital); Over-voltage and over-current protection; High-precision signal conversion; Flexible I/O configuration
-
Connection & Installation: Compatible with Honeywell T7000/WE7000 controllers; 50-pin D-Sub connector; DIN 3106 standard form factor; Easy rack-mounted installation; Clear interface identification for convenient wiring
-
Electrical Specifications: Power Supply: 24VDC (18V-32VDC range); Power Consumption: Typical 3.75W, Max 5W; Analog Input: 1 channel (0-10V or 4-20mA); Analog Output: 1 channel (0-10V or 4-20mA); Digital Input: 2 channels; Digital Output: 2 channels; Measurement Accuracy: ±0.5% F.S.; Electronic Drift: <2%
-
Environmental Ratings: Operating Temperature: -40°C to 85°C; Storage Temperature: -40°C to 85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP65
-
Mechanical Details: Housing Material: Industrial-grade high-strength metal; Dimensions: 140mm × 210mm × 40mm; Weight: Approximately 0.165kg
Recommended Honeywell Same-Series Models
-
05701-A-0301: Single-channel catalytic gas detection control card (4-20mA)
-
05701-A-0325: Single-channel infrared gas detection control card
-
05701-A-0309: Master station alarm update module kit
-
05701-A-0312: Modbus interface module kit (RS 485/RS 422)
-
05701-A-0313: Modbus interface module kit (RS 232)
-
05701-A-0314: Event printing module kit (RS 232)
-
05701-A-0326: Field interface card (sensor input only, no relay)
-
05701-A-0327: Dual SPCO relay card for Series 57
-
05701-A-0328: Triple SPCO relay card for Series 57
-
05701-A-0329: Triple DPCO relay card for Series 57
-
05701-A-0330: High-integrity dual SPCO relay card for Series 57
-
05701-A-0361: Engineering card for Series 57 system
-
05701-A-0283: 4-20mA sensor drive module for Series 57
-
05701-A-0285: Analog output module for Series 57
-
05701-A-0405: AC to DC power supply unit (16-channel, 50W)
-
05701-A-0406: AC to DC power supply unit (8-channel, 50W)
