Bently Nevada 3500/93 135785-01: Redundant Power Supply Module for Machinery Monitoring Systems
Product Description
The Bently Nevada 3500/93 135785-01 is a high-reliability redundant power supply module, a critical component of the Bently Nevada 3500 Machinery Protection and Condition Monitoring System. Designed to provide stable and uninterrupted power to the 3500 system’s monitoring modules, this module ensures continuous operation of critical machinery monitoring functions even in the event of a primary power failure. With redundant power paths, advanced fault detection, and rugged industrial design, it safeguards the integrity of machinery protection systems in demanding industrial environments, where power disruptions could lead to costly downtime or equipment damage.
Product Parameters
- Power Input: Dual AC input channels, supporting 100–240 VAC ± 10% at 50/60 Hz, enabling flexible connection to global power grids.
- Output Voltage: 24 VDC ± 0.5 V, providing stable power to 3500 series monitoring modules (e.g., vibration monitors, communication gateways).
- Output Current: Maximum 10 A total current capacity, with overload protection to prevent damage to connected modules.
- Redundancy 切换时间: <5 ms automatic transfer between primary and secondary power paths, ensuring seamless power continuity during input failures.
- Efficiency: ≥90% at full load, minimizing energy loss and reducing heat generation in enclosed system racks.
- Fault Detection: Real-time monitoring of input voltage, output voltage, and internal temperatures, with built-in diagnostics for predictive maintenance.
Product Specifications
- Operating Temperature: 0°C to 60°C, ensuring reliable performance in industrial control rooms, equipment racks, and harsh plant environments.
- Storage Temperature: -40°C to 85°C, maintaining durability during transportation, storage, and extended periods of non-operation.
- Humidity Resistance: 5% to 95% non-condensing, suitable for operation in humid industrial settings without corrosion or performance degradation.
- Dimensions: 160 mm (width) × 100 mm (height) × 220 mm (depth), designed to fit seamlessly into the 3500 system rack.
- Weight: Approximately 2.5 kg, lightweight for easy installation within the system framework.
- Protection Ratings: Overvoltage, undervoltage, and short-circuit protection; complies with IEC 61010-1 safety standards.
- Indicator Lights: LED indicators for input power status, output power status, and fault alerts, providing visual status monitoring at a glance.
- Mounting: Rack-mounted in the 3500 system enclosure, with secure locking mechanisms to prevent accidental dislodgment.
Series
The 3500/93 135785-01 belongs to the Bently Nevada 3500 series—a comprehensive suite of machinery protection and condition monitoring solutions. The 3500 series includes a wide range of modules, such as vibration monitors, position monitors, communication gateways, system controllers, and power supplies, all designed for modular integration. Renowned for its high reliability, scalability, and compliance with global standards (e.g., API 670), the series is trusted to protect critical rotating machinery in industries worldwide. The 3500/93 specifically enhances the series’ robustness by providing redundant power, a cornerstone of reliable system operation.
Features
Redundant Power Paths
Dual AC input channels with automatic <5 ms 切换 ensure uninterrupted power supply to 3500 system modules, eliminating downtime risks from single power source failures.
High Efficiency and Low Heat Generation
With ≥90% efficiency at full load, the module minimizes energy waste and reduces heat output, maintaining stable operating temperatures in enclosed racks.
Comprehensive Fault Protection
Overvoltage, undervoltage, and short-circuit protection mechanisms safeguard connected monitoring modules from electrical damage, extending system lifespan.
Real-Time Diagnostics
Built-in sensors monitor input/output voltages and internal temperatures, with fault alerts via LED indicators and system backplane communication for proactive maintenance.
Seamless System Integration
Designed exclusively for the 3500 series, it integrates with the system backplane to share status data with the system controller, enabling centralized power monitoring.
Function
The primary function of the 3500/93 135785-01 is to provide reliable, redundant power to the Bently Nevada 3500 Machinery Protection System. It converts AC input power to stable 24 VDC for distribution to monitoring modules, ensuring continuous operation of vibration, position, and temperature monitoring functions. In the event of a primary power failure, it automatically switches to the secondary input within 5 ms, preventing data loss or system shutdowns. It also monitors power quality and internal conditions, alerting operators to faults via indicators and system diagnostics to maintain system integrity.
Use
In industrial settings, the module is installed in the 3500 system rack, where it connects to dual AC power sources (e.g., main and backup generators) and distributes 24 VDC power to connected monitoring modules. It works in tandem with the system controller to provide real-time power status updates, enabling operators to monitor power health from centralized control systems. Its redundancy ensures that critical machinery monitoring continues uninterrupted, even during power grid fluctuations or input failures, making it essential for safety-critical applications.
Application Fields
Power Generation
In coal, gas, and nuclear power plants, it powers turbine and generator monitoring systems, ensuring continuous protection of assets critical to grid stability. Redundant power prevents monitoring gaps during utility power fluctuations.
Oil and Gas
For upstream drilling rigs, midstream compressors, and downstream refineries, it provides reliable power to pump and turbine monitors, supporting safe hydrocarbon production and transportation in remote or harsh environments.
Chemical Processing
In chemical plants, it powers reactor and mixer monitoring systems, ensuring uninterrupted fault detection in facilities where equipment shutdowns could lead to hazardous material leaks.
Pulp and Paper
Mills use the module to power roller and motor monitors, preventing production line disruptions caused by power failures in high-speed manufacturing processes.
Water and Wastewater
It ensures continuous power to pump and blower monitoring systems in treatment plants, safeguarding critical infrastructure for public health and environmental protection.
In summary, the Bently Nevada 3500/93 135785-01 is an indispensable component of the 3500 Machinery Protection System, providing the redundant power that underpins reliable machinery monitoring. Its robust design, seamless integration, and fault-tolerant features make it critical for industries where uninterrupted equipment protection is essential to safety, productivity, and operational efficiency.
