3BHB030833R0001 ABB Input/output module or communication interface

ABB Product: 3BHB030833R0001

Technical Parameters

1. General Specifications:
   • Device Type: I/O (Input/Output) Module or Communication Interface.
   • Compatibility: Designed for integration with ABB AC 800M PLCs, Advant Controller 800xA, or S800 I/O Systems.
   • Series: Part of ABB’s Advant OCS or Compact Product Range.
2. Electrical Specifications:
   • Supply Voltage: 24 V DC (±10%) or 110–240 V AC (auto-ranging).
   • Power Consumption: ≤15 W (typical).
   • Isolation: 1500 V AC (channel-to-channel and field-to-system isolation).
3. Communication Interfaces:
   • Primary Protocols:
     • PROFIBUS DP (up to 12 Mbps).
     • Modbus TCP/RTU.
     • Ethernet/IP.
   • Ports:
     • 1x Ethernet (RJ45, 10/100 Mbps).
     • 1x PROFIBUS DB9 connector.
   • Redundancy: Optional dual-redundant communication paths.
4. Environmental Ratings:
   • Operating Temperature: -40°C to +70°C (industrial-grade).
   • Humidity: 5–95% (non-condensing).
   • Certifications: UL, CE, IEC 61131-2, IEC 61326 (EMC compliance).
5. Mechanical Design:
   • Dimensions: Approx. 120 mm x 80 mm x 40 mm.
   • Mounting: DIN rail or panel-mounted.
   • Housing Material: Aluminum alloy (IP20/IP40 protection).
6. Software Integration:
   • Configuration Tools: Compatible with ABB Control Builder M or Automation Builder.
   • Firmware Updates: Field-upgradable via Ethernet or USB.

Key Product Functions

1. Signal Processing & I/O Handling:
   • Acquires analog/digital signals (e.g., 4–20 mA, 0–10 V, thermocouple) from sensors and actuators.
   • Provides isolation and conditioning for noise immunity in harsh environments.
2. Real-Time Communication:
   • Acts as a gateway between field devices (e.g., sensors, motors) and higher-level control systems (PLCs/DCS).
   • Supports deterministic data exchange for time-critical automation tasks.
3. Redundancy & High Availability:
   • Hot-swappable design for maintenance without system downtime.
   • Optional redundant power and communication paths for mission-critical applications.
4. Diagnostics & Health Monitoring:
   • Built-in diagnostics via LED indicators (e.g., power, communication status, fault alerts).
   • Logs system errors and communicates via SNMP or Syslog protocols.
5. Cybersecurity:
   • Supports secure communication protocols (TLS/SSL, VPN) and role-based access control (RBAC).
6. Scalability:
   • Modular architecture allows expansion with additional I/O modules (e.g., AI, DI, DO, RTD).

Typical Applications

• Process control in oil & gas, chemical, and pharmaceutical plants.
• Power generation and distribution systems (e.g., turbine control, grid automation).
• Manufacturing automation (e.g., robotics, assembly lines).
• Water/wastewater treatment and HVAC systems.
