Introduction to DAEYANG ELECTRIC 8251772
8251772 Product Overview
The DAEYANG ELECTRIC 8251772 is a high-precision intelligent temperature controller, developed by DAEYANG ELECTRIC (Deyoung Tech)—a professional manufacturer specializing in industrial automation control instruments. Tailored for temperature regulation in diverse industrial processes such as plastic molding, food processing, pharmaceutical production, and electronic component manufacturing, it serves as a core control unit to maintain stable temperature conditions for production equipment and reaction systems. A standout feature is its versatile input compatibility, supporting multiple types of temperature sensors (thermocouples, RTDs) and linear signals (voltage/current), which eliminates the need for separate controllers for different measurement scenarios. Equipped with advanced artificial PID control algorithm and automatic tuning (AT) function, it achieves zero overshoot during temperature adjustment and ensures rapid response to dynamic load changes—with a sampling rate of 30 times per second and a minimum control cycle of 0.5 seconds.
8251772 Technical Specifications
-
Product Model: 8251772
-
Product Type: Intelligent Temperature Controller
-
Core Functions: Precision temperature regulation, multi-signal input compatibility, PID auto-tuning (AT), over-temperature alarm, fast response control
-
Input Compatibility: Thermocouples (K/S/R/E/J/T/B/N/U/L/PLⅡ), RTDs (PT100/Cu50), linear voltage (0-5V/1-5V), linear current (0-20mA/4-20mA)
-
Measurement Range: -200°C to +1800°C (varies by sensor type); PT100: -200°C to +800°C; K-type thermocouple: -100°C to +1300°C
-
Control Performance: Measurement accuracy ±0.1% FS; Resolution 0.1°C (for -199.9°C to +999.9°C range); Sampling rate 30 times/sec; Control cycle 0.5-120 seconds (adjustable)
-
Output Specifications: Dual output options—Relay output (250VAC/5A, 30VDC/5A) or SSR voltage output (12VDC/30mA); Optional linear current output (0-20mA/4-20mA, 0.2% FS accuracy)
-
Alarm Functions: 1-2 configurable alarm channels; Supports upper limit, lower limit, deviation upper limit, and deviation lower limit alarms
-
Power Supply: 85-265VAC/50-60Hz (universal input); Power consumption ≤5W
-
Display & Operation: Dual 4-digit LED display (PV/SV); 4 tactile buttons for parameter setting; LED indicators for output status (OUT1/OUT2) and alarms (AL1/AL2)
-
Environmental Adaptability: Operating temperature 0°C to +50°C; Storage temperature -10°C to +60°C; Humidity 10-90% (non-condensing); Protection rating IP65 (front panel)
-
Mechanical Dimensions: Panel size 48×96mm; Cutout size 45×92mm; Depth 100mm; DIN rail or panel mount
-
Additional Features: Anti-interference design (complies with IEC 61000-4); Parameter lock function; Manual/automatic control switching
-
Certifications: CE, RoHS compliant; Complies with industrial control instrument standards
Recommended GUTOR Products
-
DAEYANG ELECTRIC 8251780: High-density temperature controller with 4 control loops, ideal for multi-zone heating systems in plastic extrusion lines.
-
DAEYANG ELECTRIC DY-01B: Compact 48×48mm temperature controller, suitable for small-scale equipment like laboratory ovens and precision incubators.
-
DAEYANG ELECTRIC 8252001: Temperature & humidity dual-control controller, designed for environmental chambers in pharmaceutical and electronics industries.
-
DAEYANG ELECTRIC DY-01E: 72×72mm temperature controller with enhanced alarm functions, protecting high-value equipment from over-temperature damage.
-
DAEYANG ELECTRIC 8253500: Modular temperature control system, supporting up to 16 slave controllers for large-scale production workshops.
-
DAEYANG ELECTRIC SSR-40DA: Solid-state relay, perfectly matching 8251772’s SSR output to drive high-power heating elements.
-
DAEYANG ELECTRIC 8251900: Communication-enabled temperature controller, supporting Modbus RTU for integration with SCADA systems.
-
DAEYANG ELECTRIC PT100-01: High-precision PT100 temperature sensor, providing accurate input signals for 8251772 in harsh industrial environments.
