Introduction to METSO A413125
A413125 Product Overview
The METSO A413125 is an industrial high-level conductivity analysis module belonging to the A413 series, specifically engineered for process automation systems in heavy industries such as mineral processing, metallurgy, and chemical manufacturing. As a key analytical component in METSO’s automation product lineup, it is designed to accurately monitor high-conductivity media and transmit reliable analytical data to upper-level control systems like DCS or PLC. Featuring a rugged industrial-grade enclosure, the module is optimized to endure harsh on-site conditions including vibration, dust, high humidity, and extreme temperature variations. It supports seamless integration with METSO’s MAX DNA distributed control system and MLCP series local control panels, ensuring continuous and stable data acquisition. Widely utilized in monitoring electrolyte concentrations in metallurgical processes, chemical reagent dosing systems, and high-conductivity process streams in mineral processing, the A413125 effectively enhances the precision and stability of industrial process control.
A413125 Technical Specifications
-
Product Model: A413125
-
Product Type: Industrial High-Level Conductivity Analysis Module
-
Core Functions: High-conductivity measurement and analysis, dual-sensor input support, real-time data transmission, system status monitoring, fault diagnosis and alarm, seamless integration with control systems
-
Power Supply: 24 VDC wide voltage input (18 VDC – 30 VDC); Built-in voltage stabilization and reverse polarity protection; Power consumption: ≤ 10 VA
-
Measurement Range: Programmable conductivity range: 0.000 to 1999 mS/cm (uncompensated)
-
Input Type: Dual-channel high-conductivity sensor input; Compatible with METSO standard conductivity sensors
-
Output Signal: Dual 4-20 mA analog outputs; Maximum load resistance: 750 Ω per channel
-
Response Performance: Response time: 1-8 seconds (depending on measuring conditions); Linearity deviation: < 3% (best fitting slope)
-
Isolation Performance: Photoelectric isolation between input, power supply and output; Isolation voltage: ≥ 2500 VAC (1 minute); Complies with IEC 61000-6-2/4 EMC standards
-
Communication Protocols: Supports PROFINET and Ethernet/IP; Seamless integration with METSO DP-100 distributed processing units
-
Protection Features: Built-in overcurrent, overvoltage and short-circuit protection; Sensor burnout protection; Dust and moisture resistant housing
-
Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection class: IP67
-
Mechanical & Installation: Compact modular design (approx. L×W×H: 120 mm × 85 mm × 45 mm); Weight: approx. 0.23 kg; DIN rail/panel-mounted; Supports hot-swapping; Compatible with M12 connectors
-
Certifications: CE, UL certified; RoHS compliant
Recommended METSO Same-Series Models
-
METSO A413111: Single-channel high-level conductivity analysis module, suitable for independent monitoring of single process streams
-
METSO A413113: High-precision conductivity analysis module with temperature compensation, ensuring measurement accuracy under temperature fluctuations
-
METSO A413140 (BIU 8): 8-channel intelligent input module with professional signal conditioning, ideal for high-precision sensor data acquisition
-
METSO A413162: Process control module, facilitating integration of analytical systems into mineral processing control loops
-
METSO A413240: 8-channel configurable input module, supporting multi-type signal acquisition for diverse monitoring scenarios
-
METSO D200533: 8-channel digital I/O module, enabling flexible signal interaction between field devices and controllers
-
METSO D200535: 16-channel configurable digital I/O module, supporting bidirectional signal transmission for large-scale control systems
-
METSO D201189L: 16-channel high-speed digital input module, suitable for large-scale industrial process monitoring
-
METSO D201466: 8-channel configurable digital I/O module with IO-Link support, realizing intelligent device diagnosis
-
METSO DP-100: Distributed processing unit, serving as the core engine of METSO MAX DNA distributed control system
-
METSO MLCP-SIE-S: Local control panel, integrating analysis and I/O modules for mill control in standard ambient environments
-
METSO MLCP-SIE-E: Local control panel, designed for mill control in extreme harsh ambient conditions
-
METSO A413126: Enhanced high-conductivity analysis module with remote calibration function, reducing on-site maintenance workload
