ABB 1TGE120011R2511 Protection Relay

ABB 1TGE120011R2511

The ABB 1TGE120011R2511 is a protection relay or control module designed for low- and medium-voltage electrical systems. While specific public documentation for this exact model is limited, it likely belongs to ABB’s portfolio of protective relays or control components, aimed at safeguarding electrical networks, equipment, and industrial processes against faults such as short circuits, overloads, or phase imbalances. Its design emphasizes reliability, precision, and seamless integration within ABB’s automation ecosystems like System 800xA or standalone protection frameworks.

Key Features (Inferred from ABB’s Protection Relay Standards):

1. Multi-Function Protection:
   • Overcurrent Protection: Definite or inverse time-delay tripping for phase and earth faults.
   • Short-Circuit Protection: Instantaneous trip for critical fault conditions.
   • Voltage Protection: Under/overvoltage monitoring for system stability.
   • Frequency Protection: Guards against grid frequency deviations.
2. Communication and Integration:
   • Supports Modbus RTU/TCP, IEC 60870-5-103/104, or IEC 61850 protocols for integration with SCADA, DCS, or substation automation systems.
   • Optional IRIG-B time synchronization for precise event logging.
3. User-Friendly Interface:
   • LCD display with multilingual menus for configuration, real-time data monitoring, and diagnostics.
   • Front-panel LEDs for status indications (e.g., power, faults, communication activity).
4. Robust Industrial Design:
   • Operates in harsh environments with a wide temperature range (-25°C to +70°C), high EMI immunity, and resistance to vibrations (IEC 60255 standards).
   • Complies with CE, UL, and IEC 60255 certifications.
5. Flexible Configuration:
   • Programmable logic (PLC-like functionality) for custom automation sequences.
   • Configurable I/O modules for digital inputs, relay outputs, and analog signals.
6. Diagnostics and Event Recording:
   • Stores fault records, waveforms, and sequence-of-events (SOE) logs for post-incident analysis.
   • Self-test functionality for continuous hardware health monitoring.

Technical Specifications (Typical for ABB Protection Relays):

• Model: 1TGE120011R2511
• Rated Voltage: Up to 690 V AC (phase-to-phase).
• Current Input: 1 A or 5 A (CT secondary).
• Communication Ports: RS-485, Ethernet, or fiber-optic interfaces (varies by variant).
• Power Supply: 24–250 V DC or 48–265 V AC.
• Mounting: DIN rail or panel-mounted.
• Certifications: CE, UL, IEC 60255, and RoHS compliant.

Applications:

This relay is ideal for safeguarding electrical infrastructure in:

• Industrial Plants: Motor, transformer, and feeder protection in manufacturing facilities.
• Power Distribution: Substation feeder protection, grid-tied renewable energy systems.
• Commercial Buildings: Critical load management and backup generator control.
• Infrastructure: Water treatment plants, transportation systems (e.g., railways, airports).
• Mining and Oil & Gas: Protection of equipment in harsh, explosive environments.

Benefits:

• Enhanced Safety: Prevents equipment damage and electrical hazards through rapid fault isolation.
• Operational Continuity: Minimizes downtime with precise fault detection and selective tripping.
• Scalability: Integrates with ABB’s System 800xA or third-party systems for unified automation.
• Future-Ready: Supports digitalization via IIoT platforms for predictive maintenance and analytics.

Configuration Notes:

• Software Tools: Configured via ABB’s PCM600 or Relion® 610 software for parameter settings, logic customization, and firmware updates.
• Network Setup: Ensure protocol compatibility (e.g., Modbus addressing, IEC 61850 SCL files).
• Testing: Perform primary injection tests to validate relay settings and CT/PT ratios.
