Introduction to ABB 216EA61b
216EA61b Product Overview
The ABB 216EA61b is a high-precision analog output module belonging to ABB’s 216 series, specifically designed for industrial distributed control systems (DCS). It serves as a core component for converting digital control signals from upper-level controllers into stable analog output signals, enabling precise regulation of actuators such as valves, motors, and regulators in industrial processes. The module features a fully modular design with galvanic isolation between channels and the system, effectively suppressing electromagnetic interference in harsh industrial environments. Equipped with self-diagnostic functions, it can promptly detect faults such as signal anomalies and circuit short circuits, and send alarm information to the upper system to ensure operational safety. Its robust structural design and wide environmental adaptability make it suitable for power generation, chemical, metallurgical and other key industrial fields, providing reliable analog signal output support for precise process control and improving the overall stability and control accuracy of the automation system.
216EA61b Technical Specifications
-
Product Model: 216EA61b
-
Product Type: Analog Output Module (216 Series)
-
Core Functions: Multi-channel analog signal output, digital-to-analog conversion, channel galvanic isolation, fault self-diagnosis & alarm, signal stability compensation, overcurrent/short-circuit protection, seamless integration with DCS
-
Power Supply: 24 V DC ±10% input; Built-in voltage stabilization and surge protection; Power consumption: ≤ 12 W (full load)
-
Output Specifications: Supports 4-20 mA DC / 0-10 V DC selectable output; Number of channels: 8; Output accuracy: ±0.1% FS; Load capacity: ≤ 500 Ω (for 4-20 mA), ≤ 1 kΩ (for 0-10 V)
-
Communication Protocols: Supports PROFIBUS DP, Modbus RTU; Compatible with ABB DCS internal communication bus; High-speed data transmission for real-time control
-
Isolation Performance: Channel-to-channel isolation: ≥ 2500 VAC; Channel-to-system isolation: ≥ 2500 VAC; Anti-interference compliance with IEC 61000-4 standards
-
Environmental Ratings: Operating temperature: -20°C to +55°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP30
-
Mechanical & Installation: DIN rail/panel-mounted; Modular design (approx. 140×100×50 mm); Weight: approx. 0.8 kg; Pluggable terminals for easy maintenance; LED status indicators for each channel
-
Compatibility: Fully compatible with ABB 216 series control systems; Matches ABB AC800F/DCS controllers and I/O modules
-
Certifications & Protection: CE, UL certified; Complies with IEC 61131-2 industrial control standards; Equipped with overcurrent, short-circuit and overtemperature protection
Recommended ABB Same-Series & Related Models
-
KONGSBERG RDI Series Communication Module: Redundant CAN bus extension module, expanding communication range for distributed RDI modules
-
ABB 216AB61 HESG324013R100: Protective relay module, for generator/transformer differential and overcurrent protection
-
ABB 216DB61 HESG324063R100: Industrial control module, integrating analog/digital signal acquisition and logic control
-
ABB 216DC61 HESG324064R100: Digital input module, specialized in high-speed acquisition of switch and sensor signals
-
ABB 216DA61 HESG324065R100: Analog input module, supporting 4-20 mA/0-10 V signal acquisition with high precision
-
ABB 216EA62b: Enhanced analog output module, with 16 channels for large-scale process control
-
ABB 216EB61 HESG324066R100: Relay output module, providing 8-channel relay output for driving industrial actuators
-
ABB 216FC61: Frequency input module, for acquisition and processing of 0-10 kHz frequency signals
-
ABB 216AB62 HESG324014R100: Redundant protective relay module, for critical power equipment protection
-
ABB 216DD61: Digital I/O module, integrating 16 digital inputs and 16 digital outputs
-
ABB 216AE61: Temperature input module, supporting PT100/K-type thermocouple signal acquisition
-
ABB 216CA61: Communication interface module, enabling 216 series modules to connect with Ethernet networks
-
ABB 216ED61: Analog I/O combination module, with 4 analog inputs and 4 analog outputs
-
ABB 216FB61: Pulse output module, supporting 0-100 Hz pulse signal output for flow control
-
ABB 216AB63 HESG324015R100: Feeder protection relay module, integrating overcurrent and earth fault protection
-
ABB 216DC62: High-speed digital input module, with 32 channels for real-time signal acquisition
