Introduction to ABB 216NG61A HESG441633R1
216NG61A HESG441633R1 Product Overview
The ABB 216NG61A HESG441633R1 is a reliable auxiliary DC power supply module belonging to ABB’s 216 series, specifically engineered for industrial automation and distributed control systems (DCS). It functions as a core power component, delivering stable 24V DC power to on-site sensors, actuators, and peripheral control devices, which is crucial for ensuring the continuous and reliable operation of the entire automation system. The module integrates comprehensive protection mechanisms, including overload, short-circuit, and surge protection, effectively safeguarding connected equipment from voltage fluctuations and abnormal current damage. With a compact modular design and flexible installation options, it is well-suited for harsh industrial environments such as power plants, chemical facilities, and manufacturing workshops. Its high compatibility allows seamless integration with ABB 216 series control systems, providing consistent and safe power support for various industrial automation scenarios.
216NG61A HESG441633R1 Technical Specifications
-
Product Model: 216NG61A HESG441633R1
-
Product Type: Auxiliary DC Power Supply Module (216 Series)
-
Core Functions: Stable 24V DC power output, overload protection, short-circuit protection, surge protection, voltage stabilization, fault self-diagnosis, power status monitoring
-
Power Specifications: Input voltage range: 36-312 V DC; Output voltage: 24 V DC (stable output with low ripple); Output power: 75 W; Power conversion efficiency: High-efficiency design for low energy consumption
-
Protection Features: Built-in overload protection (automatic recovery after fault removal); Short-circuit protection (current limiting + shutdown); Surge protection compliant with IEC 61000-4 standards; Overvoltage protection
-
Environmental Ratings: Operating temperature: -20°C to +55°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20
-
Mechanical & Installation: Rack-mounted design (2 rack divisions required); Dimensions (approx.): 262 mm × 155 mm × 20 mm; Weight: approx. 0.8 kg; Plug-and-play terminals for easy maintenance; LED status indicators (power on, fault)
-
Compatibility: Fully compatible with ABB 216 series control systems; Matches ABB Procontrol series and AC800F/DCS controllers; Supports connection with S800/S500 I/O modules
-
Performance Indicators: Output voltage accuracy: ±0.5% FS; Ripple and noise: ≤ 120 mVpp; Response time to load changes: < 50 μs; MTBF (Mean Time Between Failures): ≥ 100,000 hours
-
Certifications & Compliance: CE, UL certified; Complies with IEC 61010-1 industrial safety standards; Passes EMC (Electromagnetic Compatibility) testing
-
Application Adaptability: Suitable for power supply of DCS, PLC, industrial sensors, actuators, and other automation components in power generation, petrochemical, metallurgical, and manufacturing industries
Recommended ABB Same-Series & Related Models
-
ABB 216NG62A HESG441634R1: Auxiliary DC power supply module, 100W output power for medium-power automation scenarios
-
ABB 216NG63A: High-power auxiliary DC power supply unit, 150W output supporting parallel redundancy configuration
-
ABB 216AB61 HESG324013R100: Protective relay module, for generator/transformer differential and overcurrent protection
-
ABB 216DC61 HESG324064R100: Digital input module, specialized in high-speed acquisition of switch and sensor signals
-
ABB 216DA61 HESG324065R100: Analog input module, supporting 4-20 mA/0-10 V signal acquisition with high precision
-
ABB 216EA61b: Analog output module, providing 8-channel stable analog signals for industrial actuators
-
ABB 216VC62A HESG324442R13/C: Voltage control module, for voltage signal monitoring, regulation and protection
-
ABB 216DD61: Digital I/O module, integrating 16 digital inputs and 16 digital outputs
-
ABB 216AE61: Temperature input module, supporting PT100/K-type thermocouple signal acquisition
-
ABB 216CA61: Communication interface module, enabling 216 series modules to connect with Ethernet networks
-
ABB 216ED61: Analog I/O combination module, with 4 analog inputs and 4 analog outputs
-
ABB 216AB63 HESG324015R100: Feeder protection relay module, integrating overcurrent and earth fault protection
-
ABB 216DC62: High-speed digital input module, with 32 channels for real-time signal acquisition
-
ABB 216FB61: Pulse output module, supporting 0-100 Hz pulse signal output for flow control
-
ABB 216NG61: Entry-level auxiliary DC power supply module, 50W output for small-scale automation systems
