Introduction to ABB 3BHL000986P7001
Product Overview
The ABB 3BHL000986P7001 is a high-reliability I/O interface module tailored for ABB’s Symphony Plus distributed control system (DCS), specializing in precise conversion and reliable transmission of industrial analog and digital signals. As a critical link between field sensors/actuators and the central controller (such as HC800), it integrates 16-channel analog input and 8-channel digital output functions, supporting 4-20mA current signals from pressure, temperature, and flow sensors, as well as on/off control signals for solenoid valves and relays. Widely deployed in thermal power plants, nuclear power auxiliary systems, and large-scale petrochemical plants, it ensures accurate data acquisition and stable equipment control even in harsh environments with extreme temperatures and electromagnetic interference. Its key features include 2500Vrms optical isolation between channels, preventing cross-interference and protecting the central controller from voltage surges.
Technical Specifications
-
Product Model: 3BHL000986P7001
-
Product Type: Multi-functional I/O Interface Module for DCS
-
Series Affiliation: ABB Symphony Plus DCS Series
-
Core Functions: Analog signal acquisition, digital signal output, signal isolation conversion, real-time data transmission
-
I/O Configuration: 16×analog inputs (4-20mA), 8×digital outputs (relay type)
-
Signal Performance: Analog input accuracy ±0.1%; Input response time ≤1ms; Digital output switching time ≤10ms
-
Isolation Performance: Channel-to-channel isolation 2500Vrms; Module-to-ground isolation 1kVrms
-
Communication Interface: Symphony Plus backplane bus; Data transmission rate up to 100Mbps
-
Protection Features: Short-circuit protection per channel, overvoltage protection (2kV), surge protection
-
Power Supply: 24V DC ±15%; Redundant input supported; Power consumption ≤18W
-
Operating Environment: Temperature -20°C to +70°C; Humidity 5-95% (non-condensing); Protection rating IP20
-
Mechanical Features: Rack mount; Dimensions 160mm×110mm×45mm (L×W×H); Weight ~1.1kg
-
Compatibility: Seamless integration with ABB HC800/PP846 controllers; Supports ABB S+Engineering configuration tool
-
Certifications: CE, UL, ATEX certified; Compliant with IEC 61131-2, IEC 61010-1 standards
