Introduction to ABB 5SHY3545L0009 3BHB013085R0001
The ABB 5SHY3545L0009 (order number: 3BHB013085R0001) is a high-performance Integrated Gate-Commutated Thyristor (IGCT) power module, renowned as the “core energy converter” for medium-voltage power electronic systems. As a flagship product in ABB’s 5SHY power semiconductor series, it integrates advanced IGCT chips, anti-parallel diodes, and gate drive circuits, combining the low on-state loss of thyristors with the reliable turn-off capability of transistors. This module specializes in efficient energy conversion and precise power control in high-voltage scenarios, widely applied in medium-voltage frequency converters, HVDC transmission systems, static var compensators (SVC), and large industrial drives such as steel mill rolling mills and chemical plant pumps. Its robust industrial design features IP20 protection and a press-fit structure for direct mounting on radiators, enabling stable operation in harsh environments with temperature fluctuations from -40°C to +85°C.
3BHB013085R0001 Key Technical Specifications
-
Device Type: High-power Integrated Gate-Commutated Thyristor (IGCT) module
-
Core Functions: High-voltage energy conversion, power regulation, fast switching control, fault protection
-
Compatible Systems: ABB ACS6000 medium-voltage converters, SVC systems, HVDC transmission equipment
-
Electrical Performance: Rated voltage 45kV; rated current 3500A; surge current 40kA (10ms)
-
Switching Characteristics: Turn-off time ≤ 5μs; typical switching frequency 500Hz (up to 40kHz for short pulses)
-
Power Consumption: On-state voltage drop ≤ 2.5V; control power consumption 10-100W
-
Control Interface: Fiber-optic communication; gate drive voltage +15V/-10V
-
Cooling Method: Natural cooling; compatible with forced air/water cooling systems
-
Operating Environment: Temperature -40°C to +85°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 700mm × 450mm × 450mm; weight 160kg; rack/panel mounting
-
Protection Features: Overcurrent, overvoltage, overtemperature protection; 10μs fast fault response
-
Certifications: CE, CSA compliant; RoHS certified; meets IEC 61131-3 industrial standards
Recommended ABB Related Models
-
ABB 5SHY3545L0014 3BHB021400R0002: 3500A/45kV IGCT module, ideal for steel mill rolling mill converters
-
ABB 5SHY5045L0020: 4500A/6500V high-power IGCT module, suitable for HVDC transmission systems
-
ABB GVC736BE101 3BHE019719R0101: Gate driver module, perfectly matched with 5SHY3545L0009 for control signal transmission
-
ABB GVC750BE101 3BHE009681R0101: High-voltage driver module, complements 5SHY3545L0009 in SVC systems
-
ABB ACS6000: Medium-voltage frequency converter, core platform integrating 5SHY3545L0009
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU controller, processes power data from 5SHY3545L0009
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits 5SHY3545L0009’s data to SCADA
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes 5SHY3545L0009’s operating status and fault alerts
-
ABB REF620: Digital relay protector, safeguards 5SHY3545L0009 and associated power systems
-
ABB 5SHX2645L0006: Medium-power IGCT module, cost-effective option for small-scale medium-voltage drives
-
ABB 3BHB016120R0002: IGCT auxiliary module, enhances 5SHY3545L0009’s fault diagnosis capability
-
ABB ACS880-07: Medium-voltage converter, auxiliary drive paired with 5SHY3545L0009 in hybrid systems
-
ABB UFC762AE101 3BHE006412R0101: High-precision analog input module, collects 5SHY3545L0009’s power parameters
-
ABB AI810 3BSE032456R1: 8-channel analog input module, expands 5SHY3545L0009’s sensor signal collection
-
ABB 3BHL000389P0104: IGCT cooling accessory, ensures stable thermal management for 5SHY3545L0009
-
ABB 5SXE06-0160: Power control unit, integrates 5SHY3545L0009 for renewable energy systems View more …..
