Introduction to ABB 5SHY 3545 L0010 3BHB013088R0001

The ABB 5SHY 3545 L0010 (order number: 3BHB013088R0001) is a high-performance press-pack phase-controlled thyristor, designed for medium and high-voltage industrial power conversion scenarios. As a core component of ABB ACS6000 medium-voltage frequency converters and static excitation systems (SHEXC), it acts as a “power regulator” to precisely control the conversion and transmission of electrical energy. This thyristor excels in handling large currents and high voltages, making it widely used in industries such as metallurgy (steel rolling mills), mining (mine hoists), and power generation (generator excitation systems). Its patented Press-Pack packaging technology eliminates solders and leads, ensuring stable electrical connections even under thermal expansion, cold contraction, and mechanical vibrations—greatly enhancing long-term operational reliability in harsh industrial environments.

3BHB013088R0001 Key Technical Specifications

• Device Type: Press-pack phase-controlled thyristor
• Rated Average On-State Current (IT(AV)): 3500 A (180° conduction, double-sided cooling)
• Repetitive Peak Reverse Voltage (VRRM): 8500 V
• RMS Current (IT(RMS)): Approximately 5500 A
• Surge Current (ITSM): ≥ 65 kA (10 ms duration)
• Current Rise Rate (di/dt): ≥ 1000 A/μs
• Voltage Rise Rate (dv/dt): ≥ 1000 V/μs
• Trigger Requirements: Trigger current (IGT) ≤ 300 mA; trigger voltage (VGT) ≤ 3.0 V
• Thermal Performance: Junction-case thermal resistance (Rth(j-c)) < 0.006 K/W; operating junction temperature (Tj) -40°C to +125°C
• Cooling Method: Forced double-sided water cooling or high thermal conductivity heat sink compression
• Packaging: Disc-type Press-Pack
• Safety Certifications: Complies with IEC 60747-6, CE, UL, RoHS standards

Recommended ABB Related Models

1. ABB 5SHY 3545 L0009 3BHB013085R0001: Low-voltage variant of 5SHY 3545 series, 6500V VRRM, suitable for medium-power frequency converters in food processing plants
2. ABB 5SHY 3545 L0014: High-power IGBT module, 3kV-10kV voltage range, ideal for wind power converters and rail transit traction systems
3. ABB 5SXE 10-0180 3BHB008580R0001: High-speed thyristor module, fast switching response, used in industrial welding power supplies and UPS systems
4. ABB 5STP 27H1200: Compact IGBT module, 1200V/27A, suitable for small and medium-sized motor drive systems
5. ABB 5SHY 4045 L0010 3BHB013089R0001: High-current thyristor, 4000A IT(AV), designed for large-scale electrolytic aluminum and arc furnace systems
6. ABB 5SRL 350N12T40: Reverse-conducting thyristor, integrated freewheeling diode, used in AC-DC conversion circuits of power plants
7. ABB 5SHY 3545 L0012: High-temperature resistant thyristor, -40°C to +130°C operating range, suitable for desert oilfield pumping units
8. ABB 5STF 27N6503: 650V IGBT module with built-in protection circuit, perfect for solar PV inverters
9. ABB 3BHB013086R0001 (5SHY 3545 L0011): Explosion-proof thyristor, ATEX Zone 2 certification, used in chemical plant pressure vessel control systems
10. ABB 5SHY 2545 L0010: Medium-current variant, 2500A IT(AV), cost-effective for municipal water supply high-pressure pump systems
11. ABB 5SGF 15H6002: 600V SiC MOSFET module, high energy efficiency, suitable for new energy vehicle charging piles      View more …..
