Introduction to ABB 5SHY3545L0010 3BHB013088R0001
The ABB 5SHY3545L0010 (order number: 3BHB013088R0001) is a high-performance press-pack thyristor module, recognized as the “power conversion core” in medium-voltage industrial automation systems. As a flagship product in ABB’s 5SHY series, it is specifically designed for ABB ACS 6000 medium-voltage frequency converters and static excitation systems (SHEXC), undertaking the critical task of precise current switching and voltage regulation in high-power applications. This module excels in handling large currents and high voltages, making it a staple in industries such as metallurgy (steel rolling mill drives), mining (mine hoist power supply), and power generation (generator excitation control). Its patented press-pack structure eliminates traditional soldered connections, ensuring minimal contact resistance and efficient heat dissipation—even under extreme thermal expansion and mechanical vibration. Equipped with comprehensive protection mechanisms against overcurrent, overvoltage, and overheating, it guarantees uninterrupted operation in harsh industrial environments, directly safeguarding the reliability of the entire power drive system.
3BHB013088R0001 Key Technical Specifications
-
Device Type: Press-pack phase-controlled thyristor (SCR) module
-
Rated Reverse Repetitive Peak Voltage (VRRM/VDRM): 4500 V
-
Rated RMS On-State Current (IT(RMS)): 3500 A (180° conduction, double-sided cooling)
-
Surge Current Withstand (ITSM): ≥65 kA (10 ms single-cycle duration)
-
Gate Trigger Requirements: Trigger current (IGT) ≤ 300 mA; trigger voltage (VGT) ≤ 3.0 V
-
Switching Performance: Turn-off time (tq) ≤ 120 μs; low forward voltage drop (VF ≤ 1.8 V at rated current)
-
Thermal Characteristics: Junction-to-baseplate thermal resistance (Rth(j-c)) < 0.005 K/W; operating junction temperature (Tj) -40°C to +125°C
-
Insulation Level: 6000 V AC (1-minute dielectric withstand test)
-
Cooling Method: Double-sided forced water cooling or high-efficiency air cooling
-
Mechanical Design: Disc-type press-pack; bolt-down mounting; compatible with ABB standard heat sinks
-
Protection Features: Built-in dv/dt and di/dt suppression; integrated temperature monitoring interface
-
Certifications: CE, UL, IEC 60747-6, RoHS compliant; meets industrial safety standards for medium-voltage applications
Recommended ABB Related Models
-
ABB 5SHY3545L0009 3BHB013085R0001: Lower voltage variant (3500 V/3500 A), ideal for small to medium-sized rolling mill drives
-
ABB 5SHY4045L0004 3BHB021400R0002: High-current thyristor module (4500 A/4000 V), suitable for large mining hoist systems
-
ABB 5SHY3545L0014: Asymmetric IGCT module (4500 V/4000 A), designed for ACS 5000 series converters in petrochemical compressors
-
ABB 5SHY65L4510: High-voltage IGCT module (4500 V), specialized for HVDC and wind power inverter systems
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, coordinates with 5SHY3545L0010 in integrated drive control
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, transmits real-time control signals to the thyristor drive unit
-
ABB TP854 3BSE025349R1: 7-inch HMI, monitors 5SHY3545L0010’s temperature, current, and voltage status on-site
-
ABB AI810 3BSE032456R1: 8-channel analog input module, collects precise operational data from the thyristor module
-
ABB DO810 3BSE032452R1: 16-channel digital output module, triggers protection actions for 5SHY3545L0010 in fault scenarios
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures 2ms data transmission between controller and thyristor
-
ABB PCD237A101 3BHE028915R0101: Distributed I/O module, expands monitoring points for multi-module thyristor systems
-
ABB ACS 6000: Medium-voltage frequency converter, original application platform for 5SHY3545L0010
-
ABB 5SHY35L4510: Compact thyristor module (3500 A/4500 V), cost-effective for municipal water supply high-pressure pumps
-
ABB TB852 3BSC950263R1: Redundant analog output module, feeds precise gate control signals to 5SHY3545L0010 View more …..
