Introduction to ABB 5SHY4045L0003 3BHE019719R0101
The ABB 5SHY4045L0003 (order number: 3BHE019719R0101) is a high-voltage and high-power Integrated Gate-Commutated Thyristor (IGCT) module, hailed as the “energy conversion core” in high-power electronic systems. As a flagship product of ABB’s 5SHY series, it integrates advanced IGCT semiconductor technology with triple voltage isolation design, specializing in precise control and efficient conversion of high-voltage electrical energy. This module plays a critical role in scenarios requiring large current handling and fast switching, such as high-voltage direct current (HVDC) transmission systems, medium-voltage variable frequency drives for industrial motors, and renewable energy grid-connected inverters (wind and solar power). Its robust aluminum alloy housing ensures excellent heat dissipation and mechanical durability, while the industrial-grade EMC protection (compliant with IEC standards) enables stable operation in harsh environments with strong electromagnetic interference.
3BHE019719R0101 Key Technical Specifications
-
Device Type: High-voltage IGCT power module for energy conversion systems
-
Core Technology: Integrated Gate-Commutated Thyristor (IGCT) with fast switching capability
-
Rated Electrical Parameters: 4.5kV VRRM (reverse repetitive peak voltage); 1200A IR (rated current)
-
Switching Performance: Turn-off time ≤ 1μs; dI/dt ≈ 500A/μs (current rise rate)
-
Voltage Drop: 3.1V (on-state); 5.0V (off-state)
-
Power Dissipation: 4800W (max on-state); 1500W (max off-state)
-
Operating Environment: Temperature -40°C to +125°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 200mm × 140mm × 80mm; weight ~1.5kg
-
Mounting Method: Rack-mounted (compatible with ABB standard control cabinets)
-
Protection Features: Overcurrent, overvoltage, undervoltage protection; overtemperature alarm
-
Communication Compatibility: Supports EtherNet/IP, Profinet, Modbus for system integration
-
Certifications: CE, UL, TUV compliant; RoHS certified; suitable for ATEX Zone 2 hazardous areas
Recommended ABB Related Models
-
ABB 5SHY5055L0002 3BHE019719R0101: Higher current variant (1500A), ideal for HVDC transmission systems and large-scale wind power converters
-
ABB 5SHY4045L0006: High-voltage thyristor module, complements 5SHY4045L0003 in power system reactive compensation (SVC/STATCOM)
-
ABB ACS880-07: Medium-voltage frequency converter, core drive unit paired with 5SHY4045L0003 for industrial compressor control
-
ABB 5SDF1045H0002: 4.5kV IGBT module, alternative for high-frequency applications like photovoltaic inverters
-
ABB VM600 CPU: Rack-mounted controller, coordinates with 5SHY4045L0003 in integrated power control systems
-
ABB GVC736BE101: Gate driver module, ensures precise control of 5SHY4045L0003’s switching performance
-
ABB 5SHY3545L0020: Compact IGCT module, cost-effective option for medium-power applications like industrial heating equipment
-
ABB AGDR-61C: High-voltage IGBT driver, compatible with 5SHY4045L0003 for enhanced control reliability
-
ABB REF620: Digital relay protector, safeguards 5SHY4045L0003 from grid voltage fluctuations in power systems
-
ABB UNITROL 1020: Excitation regulator, integrates with 5SHY4045L0003 for generator energy conversion control
-
ABB PM866 3BSE050200R1: AC 800M CPU, processes real-time data from 5SHY4045L0003 in petrochemical high-power drive systems
-
ABB CI858K01 3BSE018135R1: Multi-protocol module, transmits 5SHY4045L0003’s operating data to remote SCADA
-
ABB ACS 580: Low-voltage frequency converter, auxiliary drive paired with 5SHY4045L0003 in hybrid power control systems
-
ABB NAMC-11C: Control board, provides monitoring and diagnostic functions for 5SHY4045L0003-based systems
