Introduction to ABB CI627A 3BSE017457R1
The ABB CI627A (order number: 3BSE017457R1) is a high-performance multi-protocol communication interface module, renowned as the “interconnection bridge” for ABB AC 800M and 800xA distributed control systems (DCS). As a flagship product in ABB’s S800 communication module series, it integrates diverse industrial protocol conversion capabilities and high-speed data processing functions, specializing in realizing seamless data exchange between upper-level controllers and on-site devices such as sensors, actuators, frequency converters, and remote I/O stations. This module supports multiple mainstream protocols including DeviceNet, Modbus RTU/TCP, EtherNet/IP, and PROFINET, making it widely applicable in discrete manufacturing (automobile welding lines, packaging machinery), process industries (petrochemical, food and beverage), and logistics automation (conveyor systems, intelligent warehouses). Its robust industrial-grade design features 500V AC galvanic isolation between ports and backplanes, effectively resisting electromagnetic interference in complex industrial environments, while the compact DIN rail mounting structure saves cabinet space.
3BSE017457R1 Key Technical Specifications
-
Device Type: Multi-protocol industrial communication interface module (DeviceNet Master/Scanner)
-
Core Functions: Protocol conversion, high-speed data transmission, device status monitoring, fault diagnosis
-
Compatible Systems: ABB AC 800M PLC, 800xA DCS, Symphony®Plus control system
-
Protocol Support: DeviceNet (Conformance Class 3), Modbus RTU/TCP, EtherNet/IP, PROFINET; supports protocol switching
-
Communication Performance: DeviceNet rates 125/250/500 kbps; Ethernet rate 10/100 Mbps; maximum 64 slave nodes
-
I/O Capability: 2048 I/O ports (expandable to 4096); supports polling and bit-strobed data transmission
-
Power Supply: +5V DC (from system backplane); optional 24V DC external power for bus
-
Memory Configuration: 1 MB RAM for data storage and program execution
-
Processing Performance: 200 MHz CPU; data processing latency ≤ 5ms
-
Operating Environment: Temperature 0°C to +55°C (operating); -40°C to +85°C (storage); humidity 5-95% (non-condensing)
-
Physical Specifications: 120mm × 80mm × 40mm; weight ~0.2kg; 35mm DIN rail mounting
-
Protection Features: 500V AC isolation (port-backplane); EMC compliant with IEC 61000-4; overcurrent protection
-
Certifications: CE, UL compliant; RoHS certified; meets IEC 61131-2 and DeviceNet specifications
Recommended ABB Related Models
-
ABB CI854K01 3BSE025961R1: PROFIBUS DP/DP-V1 interface module, ideal for connecting Siemens devices with AC 800M
-
ABB CI810B 3BSE013241R1: Industrial Ethernet (TCP/IP) module, complements CI627A for Ethernet-based device integration
-
ABB CI522A 3BSE013261R1: PROFIBUS DP communication module, cost-effective option for medium-speed data transmission
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU controller, core processing unit for CI627A-transmitted data
-
ABB AI810 3BSE032456R1: 8-channel analog input module, pairs with CI627A for sensor signal collection in automotive plants
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control actions based on CI627A’s commands
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes CI627A’s communication status and device fault alerts
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, extends CI627A’s compatibility with remote SCADA systems
-
ABB AC500 PLC: Compact controller, uses CI627A for small-scale packaging line device interconnection
-
ABB ACS880-07: Medium-voltage frequency converter, communicates with AC 800M via CI627A
-
ABB UFC762AE101 3BHE006412R0101: High-precision analog input module, transmits power parameters to CI627A
-
ABB REF620: Digital relay protector, safeguards CI627A and associated communication circuits
-
ABB TU843 3BSE021443R1: S800 I/O terminal base, provides stable connection for CI627A and I/O modules
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data interaction with CI627A
-
ABB PM803 3BSE008572R1: Entry-level AC 800M CPU, cost-effective match for CI627A in small automation projects
-
ABB 3BSE025349R1 TP854: HMI with touchscreen, enables on-site configuration of CI627A’s communication parameters View more …..
