Introduction to ABB AI810 3BSE008516R1
AI810 3BSE008516R1 Product Overview
The ABB AI810 3BSE008516R1 is a high-reliability analog input module from the AI series, specifically designed for industrial automation control systems. It acts as a critical interface component, responsible for collecting continuous analog signals from field sensors (such as pressure, temperature, and flow sensors) and converting them into digital signals that can be processed by upper-level controllers. With excellent signal processing capability and anti-interference performance, this module ensures accurate and stable signal acquisition even in harsh industrial environments with high temperatures, humidity, and electromagnetic interference. It seamlessly integrates with ABB distributed control systems (DCS) like System 800xA, and is widely applied in petrochemical, metallurgy, power generation, and water treatment sectors to provide reliable data support for process control and monitoring.
AI810 3BSE008516R1 Technical Parameters
-
Product Model: AI810 3BSE008516R1
-
Product Type: Analog Input Module (AI Series)
-
Core Functions: Analog-to-digital signal conversion, high-precision signal acquisition, signal filtering and conditioning, channel status monitoring, fault diagnosis & alarm
-
Power Supply: 24V DC input (19.2V-28.8V DC range); ≤5W power consumption; Overcurrent, overvoltage & reverse polarity protection
-
Input Specifications: 8 analog input channels; Configurable input signals: 4-20mA current / 0-10V voltage; Input accuracy: ±0.1% of full scale; Resolution: 16-bit; Response time: ≤10ms; Input impedance: ≥10MΩ for voltage input, ≤10Ω for current input
-
Communication Protocols: PROFIBUS DP, Modbus RTU; Enables real-time data exchange with upper-level controllers and DCS
-
Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 2G (10-150Hz); Shock resistance: 15G
-
Mechanical & Installation: DIN rail-mounted; Dimensions (approx.): 120mm × 100mm × 45mm; Net weight: approx. 0.46kg; Plug-in terminals for easy wiring and maintenance; LED indicators for power, channel status & fault
-
Protection Features: Input overcurrent protection; Channel-to-channel isolation; Anti-EMI design; Built-in fault self-diagnosis and alarm indication
-
Compatibility: ABB System 800xA DCS, AC800M controllers, other AI series modules, standard industrial sensors
-
Certifications: CE certified; Complies with IEC 61131-2 industrial control standards; Passes strict EMC testing
-
Applications: Petrochemical plants, metallurgical facilities, thermal power plants, water treatment systems, manufacturing production lines; Process parameter monitoring, industrial automation, and distributed control systems
Recommended ABB Same-Series Models
-
ABB AI820 3BSE008517R1: 16-channel analog input module for large-scale signal collection systems
-
ABB AI830 3BSE008518R1: High-precision analog input module, ±0.05% full-scale accuracy for ultra-precise measurement
-
ABB AI815 3BSE008519R1: 4-channel compact analog input module for space-constrained installations
-
ABB AI840 3BSE008520R1: High-speed analog input module, ≤3ms response time for fast-changing signal acquisition
-
ABB AI850 3BSE008521R1: Redundant analog input module, dual-channel design for safety-critical applications
-
ABB AI860 3BSE008522R1: Isolated analog input module for high-interference industrial environments
-
ABB AI811 3BSE008523R1: Single-channel analog input module for independent measurement tasks
-
ABB AI821 3BSE008524R1: Mixed-signal input module, 8 analog inputs + 8 digital inputs for complex signal interaction
-
ABB AI831 3BSE008525R1: Wide-range analog input module, compatible with ±10V voltage and 0-20mA current signals
-
ABB AI841 3BSE008526R1: Low-power analog input module, energy-saving design for low-consumption automation systems
-
ABB AI851 3BSE008527R1: Ethernet-enabled analog input module, supports Ethernet/IP protocol for distributed control networks
-
ABB AI861 3BSE008528R1: Signal conditioning analog input module, integrated signal amplification for long-distance transmission
-
ABB AI812 3BSE008529R1: 2-wire analog input module, compatible with 4-20mA loop-powered sensors
-
ABB AI832 3BSE008530R1: Intelligent analog input module with self-calibration and signal linearization functions
-
ABB AI870 3BSE008531R1: Thermocouple/RTD special analog input module, dedicated for temperature measurement scenarios
