Introduction to ABB B3EA HENF315147R1
HENF315147R1 Product Overview
The ABB B3EA HENF315147R1 is a high-stability industrial signal conversion module, specifically designed for precise signal processing in industrial automation and process control systems. It functions as a key interface between field sensors and upper-level control units, specializing in converting and isolating analog signals from critical process parameters such as temperature, pressure, and flow. Equipped with industrial-grade signal conditioning technology, the module effectively filters out electromagnetic interference and voltage fluctuations, ensuring accurate and reliable signal transmission even in harsh industrial environments like petrochemical plants, power stations, and manufacturing facilities. Featuring a compact and rugged design with DIN rail mounting capability, it allows for easy integration into existing control cabinets and flexible system expansion. This module is widely recognized for its low power consumption and maintenance-free operation, providing robust support for enhancing the stability and efficiency of industrial control systems.
HENF315147R1 Technical Specifications
-
Product Model: B3EA HENF315147R1
-
Product Type: Industrial Signal Conversion Module
-
Core Functions: Analog signal conversion, signal isolation, interference filtering, data transmission, fault self-diagnosis
-
Input Signal: Supports 4-20mA, 0-10V analog signals; Compatible with temperature, pressure, flow sensors
-
Output Signal: Standard 4-20mA analog output; Conversion accuracy ≤0.1% FS
-
Communication Capability: Supports Modbus RTU, PROFIBUS DP protocols; Seamless integration with mainstream DCS/PLC systems
-
Power Supply: 24V DC ±10%; Power consumption ≤5W
-
Isolation Performance: Input-output isolation voltage ≥1500V AC; Channel-channel isolation ≥500V AC
-
Operating Environment: Temperature range: -25°C to +65°C; Humidity: 5-95% (non-condensing); Complies with IEC 61000-6-2/4 EMC standards
-
Mechanical Dimensions: 35mm × 100mm × 115mm; Weight: Approximately 0.18kg
-
Safety Features: Overvoltage protection, short-circuit protection, reverse polarity protection
-
Installation Method: 35mm DIN rail mounting; Tool-free wiring terminals
-
Certifications: CE, UL, IEC 61131-2 compliant; Suitable for global industrial applications
