Introduction to ABB BC810K01 3BSE031154R1
BC810K01 3BSE031154R1 Product Overview
The ABB BC810K01 3BSE031154R1 is a high-reliability CEX-Bus interconnection unit, specifically engineered to facilitate seamless communication and module interconnection within ABB automation systems such as Advant 800xA. As a critical bridging component in the system, it is responsible for connecting various devices and modules on the CEX-Bus, enabling stable and efficient data exchange and signal transmission between different system segments. This module features a integrated kit design, including the interconnection unit, baseplate, and CEX-Bus terminator, which simplifies installation and system configuration. With excellent anti-electromagnetic interference capability and robust structural design, it can adapt to harsh industrial environments such as power generation, oil and gas, and petrochemical facilities. Its high compatibility allows seamless integration with ABB AC800M series controllers and other CEX-Bus compatible modules, supporting redundant communication interfaces and hot-swap functionality to ensure the continuous and reliable operation of the entire automation system.
BC810K01 3BSE031154R1 Technical Specifications
-
Product Model: BC810K01 3BSE031154R1
-
Product Type: CEX-Bus Interconnection Unit
-
Core Functions: CEX-Bus module interconnection, seamless data exchange between system segments, redundant communication support, on-line CPU replacement facilitation, hot-swap capability, external power supply management, system communication status monitoring
-
Kit Components: BC810 interconnection unit; TP857 baseplate (width = 60 mm); TB850 CEX-Bus terminator
-
Power Supply: External 24 V DC power supply; Built-in power voting diode and fuse for protection; Power consumption: Low power design
-
Performance Indicators: Supports redundant communication interface units; Enables on-line replacement of CPU without disrupting CEX traffic; Supports hot-swap for easy maintenance; Ensures stable data transmission on CEX-Bus
-
Communication Features: Dedicated to CEX-Bus communication; Provides reliable connection for CEX-Bus devices; Facilitates efficient data exchange between system modules
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20 (for cabinet installation); Vibration resistance: 10-150 Hz, 0.15 mm amplitude
-
Mechanical & Installation: DIN rail-mounted design (baseplate grounded to DIN-rail); Dimensions (approx.): 127.5 mm × 185 mm × 59 mm; Weight: approx. 0.6 kg; Pluggable connectors for easy wiring and maintenance; LED status indicators (power, communication status, fault)
-
Compatibility: Fully compatible with ABB Advant 800xA system; Seamless integration with ABB AC800M series controllers; Compatible with other CEX-Bus compliant modules and devices
-
Certifications & Compliance: CE certified; Complies with relevant industrial automation system interconnection standards; Passes strict EMC (Electromagnetic Compatibility) testing
-
Application Adaptability: Suitable for ABB automation systems in industries such as power generation, oil and gas, petrochemical, and process manufacturing; Ideal for CEX-Bus system expansion, redundant communication configuration, and distributed control system interconnection scenarios
Recommended ABB Same-Series & Related Models
-
ABB BC810K02: CEX-Bus interconnection unit, enhanced redundant communication support for large-scale automation systems
-
ABB TB850 3BSE018139R1: CEX-Bus terminator, matching BC810 series for CEX-Bus network termination
-
ABB TP857: 60mm width baseplate, dedicated to BC810 series interconnection unit installation
-
ABB BC811K01: CEX-Bus extension unit, expanding CEX-Bus network coverage for large-scale system layout
-
ABB BC812K01: CEX-Bus redundant interconnection unit, dual-channel design for safety-critical system communication
-
ABB CI854A 3BSE030221R1: PROFIBUS communication module, compatible with BC810 series for multi-protocol communication expansion
-
ABB AC800M PM861K01 3BSE018105R1: CPU module, matching BC810 series for small-scale CEX-Bus based automation systems
-
ABB TB852 3BSC950263R1: Distributed I/O module, compatible with BC810 interconnection unit for field data acquisition and control
-
ABB BC820K01: CEX-Bus to Ethernet gateway module, enabling data exchange between CEX-Bus and Ethernet networks
-
ABB TP858: Wide-width baseplate, supporting multi-module installation with BC810 series interconnection units
-
ABB BC830K01: CEX-Bus communication monitoring module, real-time monitoring of CEX-Bus data transmission status
-
ABB AC800M PM864AK01 3BSE018161R1: High-performance CPU module, paired with BC810 series for large-scale distributed control systems
-
ABB TB862 3BSC950273R1: High-speed distributed I/O module, compatible with BC810 for high-dynamic data acquisition scenarios
-
ABB BC840K01: CEX-Bus redundant power supply module, ensuring stable power supply for BC810 interconnection units
-
ABB PP835A 3BSE042234R2: Process panel, matching BC810-based systems for local operation and monitoring
