Introduction to ABB CI570 3BSE001440R1

CI570 3BSE001440R1 Product Overview

CI570 3BSE001440R1 Technical Parameters

• Product Model: CI570 3BSE001440R1
• Product Type: Communication Interface Module (CI Series, DeviceNet Bus)
• Core Functions: DeviceNet protocol conversion, real-time data transmission, network management, communication status monitoring, fault diagnosis & alarm
• Power Supply: 24V DC input (19.2V-28.8V DC range); Power consumption: ≤5W; Overcurrent, overvoltage & reverse polarity protection
• Communication Specifications: Supports DeviceNet bus protocol; Communication rate: 125Kbps, 250Kbps, 500Kbps (switchable); Maximum number of connected nodes: 64; Communication distance: Up to 500m (125Kbps), 250m (250Kbps), 100m (500Kbps)
• Interface Type: 1 x DeviceNet port (5-pin mini Delta); 1 x internal backplane interface for controller connection
• Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 2G (10-150Hz); Shock resistance: 15G
• Mechanical & Installation: DIN rail-mounted; Dimensions (approx.): 120mm × 100mm × 45mm; Net weight: approx. 0.45kg; Plug-in terminals for easy wiring; LED indicators for power, communication status & fault
• Protection Features: ESD protection (±15kV contact, ±8kV air); Overvoltage protection for communication ports; Anti-EMI design; Built-in fault self-diagnosis and alarm indication
• Compatibility: ABB AC800M controllers, ABB System 800xA DCS, other CI series modules, DeviceNet-compliant field devices
• Certifications: CE certified; Complies with IEC 61131-2 industrial control standards and ODVA DeviceNet specifications; Passes strict EMC testing
• Applications: Automotive manufacturing lines, electronic component production facilities, petrochemical plants, metallurgical workshops; Industrial automation communication networks, DCS-controller-field device data transmission scenarios
