Introduction to ABB CI858K01 3BSE018135R1
The ABB CI858K01 (order number: 3BSE018135R1) is a high-performance multi-protocol communication module, renowned as the “interconnection hub” for industrial automation systems. As a key component of ABB’s AC 800M DCS platform, it specializes in enabling seamless data exchange between controllers and field devices by supporting multiple communication protocols, including DriveBus, PROFIBUS DP, Modbus RTU, and RS-232. This module plays a critical role in connecting ABB controllers with drives, remote I/O units, and upper-level monitoring systems, making it widely applied in power generation, petrochemical, metallurgy, and robotics industries. Its robust design features industrial-grade EMC shielding and wide temperature adaptability (-40°C to +85°C), ensuring stable operation in harsh environments with strong electromagnetic interference. The compact DIN rail-mounted structure saves cabinet space, while built-in self-diagnostic functions and LED status indicators simplify on-site troubleshooting, significantly enhancing the reliability and maintainability of communication networks.
3BSE018135R1 Key Technical Specifications
-
Device Type: Multi-protocol industrial communication module for AC 800M systems
-
Supported Protocols: DriveBus, PROFIBUS DP, Modbus RTU, RS-232, Ethernet/IP
-
Communication Rates: PROFIBUS DP up to 960 kbps; Modbus RTU 9600 bps-115200 bps; RS-232 9600 bps
-
Connection Capacity: Up to 31 field devices; compatible with ABB drives and third-party I/O units
-
Power Supply: 24V DC ±20%; typical current consumption 100mA
-
Operating Environment: Temperature -40°C to +85°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 124mm × 74mm × 44mm; weight ~0.3kg (bare module), 0.55kg (with baseplate)
-
Mounting Method: 35mm DIN rail mounting; compatible with S800 I/O series
-
Interface Types: DriveBus interface, 9-pin Sub-D (PROFIBUS DP), RS-232 port
-
Protection Features: EMC compliant with IEC 61158; overvoltage protection; short-circuit isolation
-
Diagnostic Functions: Built-in status monitoring; fault alarm output; error counting and logging
-
Certifications: CE, RoHS compliant; meets industrial communication safety standards
Recommended ABB Related Models
-
ABB CI858K02 3BSE018136R1: Enhanced protocol variant, supports CANopen for automotive assembly line applications
-
ABB CI858K04 3BSE018138R1: Quad-interface version, ideal for complex logistics sorting systems with multi-device connections
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, core unit paired with CI858K01 for integrated DCS in power plants
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS DP-V1 module, complements CI858K01 for 12 Mbps data transmission
-
ABB CI854AK01 3BSE030220R1: PROFIBUS DP-V1 communication module, expands CI858K01’s network coverage in petrochemical plants
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes CI858K01’s communication status and fault information
-
ABB AI810 3BSE032456R1: 8-channel analog input module, transmits sensor data to controller via CI858K01
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control commands received by CI858K01
-
ABB CI853K01 3BSE018103R1: Dual RS232-C communication module, pairs with CI858K01 for serial communication expansion
-
ABB CI857K01 3BSE018144R1: INSUM communication module, connects CI858K01 to ABB’s distributed control networks
-
ABB ACS 580: Low-voltage frequency converter, communicates with controller via CI858K01 for motor speed control
-
ABB AC500 PLC: Compact programmable controller, uses CI858K01 for multi-device connection in packaging lines
-
ABB TB850 3BSC950193R1: CEX bus terminal (pin type), ensures stable signal transmission for CI858K01
-
ABB BC810K02 3BSC031155R1: CEX bus interconnection module, expands CI858K01’s bus connection capacity View more …..
