Introduction to ABB CI858K01 3BSE018135R1
CI858K01 3BSE018135R1 Product Overview
The ABB CI858K01 3BSE018135R1 is a high-performance industrial Ethernet communication module belonging to the ABB CI858 series, specifically designed to enable high-speed and reliable data exchange in industrial automation systems. As a critical communication bridge between ABB controllers and various industrial network devices, it is responsible for transmitting control commands, process data, and status information between upper-level control systems, field devices, and human-machine interfaces. Equipped with advanced Ethernet communication technology, this module supports high-bandwidth data transmission, ensuring real-time and accurate data interaction even in large-scale and complex automation scenarios. With a robust modular structure and excellent anti-electromagnetic interference capability, it can adapt to harsh industrial environments such as petrochemical plants, power stations, and large-scale manufacturing facilities.
CI858K01 3BSE018135R1 Technical Specifications
-
Product Model: CI858K01 3BSE018135R1
-
Product Type: High-Performance Industrial Ethernet Communication Module (CI858 Series)
-
Core Functions: Industrial Ethernet data transmission, multi-protocol conversion, real-time data exchange, network status monitoring, fault self-diagnosis, remote configuration, data encryption
-
Communication Specifications: Ethernet ports: 2 x RJ45 (10/100/1000 Mbps, auto-negotiation); Supported protocols: PROFINET IO, Ethernet/IP, Modbus TCP, OPC UA; Data transmission rate: Up to 1 Gbps; Supports TCP/IP, UDP/IP network protocols; Supports network redundancy (MRP, PRP)
-
Power Supply: 24 V DC ±10% input (18-32 V DC range); Power consumption: ≤ 8 W; Built-in overcurrent, overvoltage protection and voltage stabilization circuit
-
Performance Indicators: Data processing latency: < 1 ms; Supports up to 100 concurrent network connections; Maximum data frame length: 9000 bytes (Jumbo Frame); Supports time synchronization via IEEE 1588 PTP (Precision Time Protocol)
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20 (for cabinet installation); Vibration resistance: 10-150 Hz, 0.15 mm amplitude
-
Mechanical & Installation: DIN rail-mounted design; Dimensions (approx.): 100 mm × 140 mm × 60 mm; Weight: approx. 0.4 kg; Pluggable terminals for easy maintenance; LED status indicators (power, link status, data transmission, fault)
-
Compatibility: Fully compatible with ABB AC800 series controllers (AC800M, AC800V); Seamless integration with ABB System 800xA; Supports connection with third-party Ethernet-compatible devices via standard protocols
-
Certifications & Compliance: CE, UL certified; Complies with IEC 61158, IEC 61784 industrial communication standards; Passes strict EMC (Electromagnetic Compatibility) testing
-
Application Adaptability: Suitable for communication integration in industrial automation systems such as petrochemical, power generation, metallurgy, and discrete manufacturing; Ideal for DCS system networking, field device interconnection, and remote monitoring systems
