Introduction to ABB G3EA HENF315754R1
G3EA HENF315754R1 Product Overview
The ABB G3EA HENF315754R1 is a versatile industrial automation controller module, engineered to deliver precise control, real-time monitoring, and reliable protection for diverse industrial scenarios—ranging from robot control in manufacturing workshops and process regulation in petrochemical plants to power measurement systems and medical equipment calibration. As a key member of ABB’s G3 series, it stands out with its broad environmental adaptability, operating stably in extreme temperatures from -40°C to 60°C, which makes it suitable for both cold storage automation and high-temperature industrial zones. A core advantage is its multi-type I/O support, integrating digital, analog, relay, and transistor inputs to connect seamlessly with various field sensors and actuators. Equipped with IP65 protection rating, it resists dust and water splashes, enabling direct installation in semi-outdoor or harsh on-site environments without additional enclosures.
G3EA HENF315754R1 Technical Specifications
-
Product Model: G3EA HENF315754R1
-
Product Type: Industrial Automation Controller Module
-
Series Affiliation: ABB G3 Series Industrial Automation Modules
-
Core Functions: Precision control, real-time monitoring, equipment protection, multi-protocol data transmission
-
I/O Configuration: Supports digital/analog/relay/transistor inputs; Configurable I/O mapping via software
-
Control Performance: Control precision ±0.5%; Instruction response time ≤1ms; Output frequency 0-65Hz
-
Communication Capability: Supports Modbus RTU, Profibus DP, Ethernet/IP; RS-485 & RJ45 interfaces
-
Power Supply: 24V DC ±20%; Max input current 5mA; Power consumption ≤8W
-
Output Specifications: Relay output; Output voltage range 0-416V AC; Output current rating 2A
-
Protection Features: Overload protection, short-circuit protection, overheating protection, ESD protection
-
Operating Environment: Temperature -40°C to +60°C; Humidity 5-95% (non-condensing); Protection rating IP65
-
Mechanical Features: Compact design; Dimensions 120mm×80mm×50mm (L×W×H); Weight ~200g
-
Programmability: Supports custom control logic; Compatible with ABB standard programming software
-
Compatibility: ABB AC 800M DCS, S800 I/O modules, ACS series converters, third-party PLCs
-
Certifications: CE, UL certified; Complies with industrial control safety standards
Recommended ABB Products
-
ABB PM864AK02 3BSE018161R1: AC 800M CPU module that synchronizes complex control strategies with G3EA HENF315754R1.
-
ABB AI835 3BSE008520R1: High-precision analog input module that provides sensor data for G3EA HENF315754R1’s control algorithms.
-
ABB CI854A 3BSE022363R1: Profibus DP module that expands G3EA HENF315754R1’s connectivity to fieldbus devices.
-
ABB ACS880-01-04A6-2: Low-voltage frequency converter that receives speed control signals from G3EA HENF315754R1.
-
ABB Panel 800: Industrial HMI panel that displays real-time data and alarms from G3EA HENF315754R1.
-
ABB PU515A 3BSE032401R1: Redundant power supply that ensures stable 24V DC input for G3EA HENF315754R1.
-
ABB REF615 1MRK504153-BEN: Protection relay that sends fault signals to G3EA HENF315754R1 to trigger safety actions.
-
ABB DI830 3BSE008519R1: Digital input module that supplements G3EA HENF315754R1’s signal acquisition capability.
-
ABB G3FD HENF452692R1: G3 series control card that works with G3EA HENF315754R1 for redundant control.
-
ABB 1TGE120010R1300: HMI operating unit that allows on-site configuration of G3EA HENF315754R1’s parameters.
