Introduction to ABB GFD233A103 3BHE022294R0103

GFD233A103 3BHE022294R0103 Product Overview

GFD233A103 3BHE022294R0103 Technical Specifications

• Product Model: GFD233A103 3BHE022294R0103
• Product Type: Multi-Functional Control Module (GFD Series)
• Core Functions: Process control and monitoring, real-time data processing, voltage/current regulation, signal conditioning, multi-protocol communication, fault detection and diagnosis
• Electrical Parameters: Input voltage: 220 VAC; Output voltage: 0-10 VDC; Rated current: 10 A; Supports both analog and digital I/O signals
• Power Supply: 24 VDC input (±20% range); Built-in overcurrent, overvoltage and reverse polarity protection
• Communication Interfaces: Supports Ethernet, RS-485 serial communication; Compatible with Modbus, PROFIBUS and PROFINET protocols
• Performance Indicators: Equipped with high-performance processor for fast response; Supports online parameter configuration and debugging; Enables seamless data exchange with upper-level controllers
• Environmental Ratings: Operating temperature: -10°C to +50°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20
• Mechanical & Installation: Wall-mounted or panel-mounted design; Dimensions (approx.): 100 mm × 80 mm × 50 mm; Net weight: approx. 0.5 kg; Housing material: Aluminum alloy; LED indicators for power, operation and fault status
• Compatibility: ABB distributed control systems; Standard industrial sensors, actuators and PLC systems; Supports I/O expansion via additional modules
• Certifications & Compliance: CE certified; Complies with relevant industrial control standards; Passes strict EMC (Electromagnetic Compatibility) testing
• Application Adaptability: Suitable for power generation, manufacturing, petrochemical, water treatment and transportation industries; Ideal for generator excitation control, production line monitoring, energy management and traffic signal control scenarios

Recommended ABB Same-Series & Related Models

1. ABB GFD230A: GFD series basic control module, supports core process control for simple automation systems
2. ABB GFD231A 3BHE022292R0101: GFD series enhanced control module, specialized in signal conditioning and data acquisition
3. ABB GFD235A101 3BHE032025R0101: GFD series excitation control module, tailored for synchronous generator excitation systems
4. ABB GFD563A101 3BHE046836R0101: GFD series high-performance control module, supports PROFIBUS DP-V1 and line redundancy
5. ABB GFD215 3BHE013266R0101: GFD series digital I/O module, 16 DI/16 DO for discrete control tasks
6. ABB GFD225 3BHE013267R0101: GFD series analog output module, 8-channel for multi-actuator control
7. ABB GFD240 3BHE022296R0101: GFD series communication extension module, expands PROFINET connectivity
8. ABB GFD250 3BHE022297R0101: GFD series redundant control module, dual-channel design for safety-critical applications
9. ABB GFD237: GFD series advanced control module, integrates enhanced data processing and energy management functions
10. ABB AC800M PM861K01 3BSE018105R1: Standard CPU module, matches GFD series for distributed control systems
11. ABB CI854A 3BSE030221R1: PROFIBUS communication module, enhances fieldbus integration with GFD series
12. ABB AI810 3BSE020510R1: Analog input extension module, supplements GFD series’ data acquisition capability
13. ABB AO810 3BSE020512R1: Analog output extension module, expands GFD series’ control signal coverage
14. ABB PS865 3BSE025266R1: Stable power supply module, supports reliable operation of GFD series modules
15. ABB PP835A 3BSE042234R2: Local process panel, enables on-site operation and monitoring for GFD-based systems
