Introduction to ABB INICT01
Product Overview
The ABB INICT01 is a dedicated Infi-Net computer transfer module, specifically designed for the Bailey INFI 90 Distributed Control System (DCS). As a key communication component in ABB’s industrial automation lineup, it serves as a reliable data bridge between the INFI 90 system’s high-speed Infi-Net network and external computer systems. The module enables seamless data exchange via standard RS-232-C serial interface, supporting operations such as DCS data access, real-time monitoring, configuration, diagnosis, and historical data analysis. Featuring a rugged modular design optimized for industrial environments, it ensures stable communication performance even in harsh conditions with temperature fluctuations and electromagnetic interference. Widely applied in power generation, petrochemical, and process industries, the INICT01 facilitates efficient integration between DCS and enterprise-level IT systems (e.g., MES, ERP), laying a solid foundation for advanced factory automation and information management.
Technical Specifications
-
Product Model: INICT01
-
Product Type: Infi-Net Computer Transfer Module
-
Core Functions: Data transmission between Infi-Net network and external computers, time synchronization for control processes, multi-type message handling, data integrity check, system configuration and diagnosis
-
Power Supply: 24 VDC input; Typical power consumption: 10 W; Supports voltage stabilization and surge protection
-
Communication Interface: Two full-duplex serial EIA standard RS-232-C ports; User-selectable communication rate: 50 to 19,200 baud
-
Memory Configuration: 256 kbytes ROM, 512 kbytes RAM, 80 kbytes NVRAM
-
Message Handling: Supports four message types (broadcast, time synchronization, multicast, NIS poll); Equipped with CRC and checksum for data integrity
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Protection class: IP20
-
Mechanical & Installation: Compact modular design (approx. 70 × 37 × 20 mm); Weight: approx. 120 g; Occupies two slots in standard INFI 90 module mounting unit; Front panel LED indicators for status monitoring
-
System Compatibility: Fully compatible with ABB Bailey INFI 90 distributed control system
-
Certifications: Complies with industrial communication and safety standards
Recommended ABB Same-Series Models
-
ABB INCIT01: Infi-Net computer transfer module, facilitating communication between INFI 90 system and external computing devices
-
ABB INNIS01: Infi-Net network interface slave module, serving as a key node for Infi-Net network communication
-
ABB INPM01: Process monitoring module, enabling real-time collection and analysis of industrial process parameters
-
ABB INCT01: Communication interface module, supporting data exchange between DCS and multiple external devices
-
ABB INLM01: Local control module, realizing localized control and monitoring of on-site equipment
-
ABB INPD01: Process data acquisition module, specialized in high-precision collection of analog and digital process signals
-
ABB INAL01: Analog input module, providing high-accuracy conversion for analog signals from sensors
-
ABB INDL01: Digital input module, supporting fast response acquisition of digital signals from field switches
-
ABB INDO01: Digital output module, driving on-site actuators such as relays and contactors
-
ABB INCC01: Control configuration module, enabling custom configuration of control strategies for DCS
-
ABB INMD01: Module diagnosis module, supporting real-time fault diagnosis and status monitoring of DCS modules
-
ABB INSC01: System synchronization module, ensuring time synchronization of all nodes in the distributed control system
