Introduction to ABB KUC720AE01 3BHB003431R0101
The ABB KUC720AE01 (order number: 3BHB003431R0101) is a high-performance multi-functional control module, recognized as the “intelligent control core” in industrial automation systems. As a versatile product in ABB’s KUC series, it integrates motion control, logic processing, and data communication capabilities, supporting position, speed, and torque control modes to adapt to diverse scenarios—from robot motion regulation in automotive manufacturing to generator excitation control in power plants, and process parameter adjustment in petrochemical reactors. Powered by a 32-bit DSP processor with 550μs high-speed processing capacity, this module ensures real-time response to complex control commands. Its robust design features industrial-grade EMC protection and wide environmental adaptability, maintaining stable operation amid strong electromagnetic interference and temperature fluctuations. The modular structure supports hot-swapping, while built-in fault diagnosis and remote maintenance functions simplify on-site management, significantly enhancing the reliability and operational efficiency of automation systems across manufacturing, power, and process industries.
3BHB003431R0101 Key Technical Specifications
-
Device Type: Multi-functional industrial control module (motion control + logic processing)
-
Core Processor: 32-bit digital signal processor (DSP); processing speed 550μs
-
I/O Configuration: 24 I/O points; supports digital/analog hybrid input/output
-
Control Modes: Position control, speed control, torque control; switchable per application
-
Communication Protocols: Modbus RTU, PROFIBUS, RS485/232, CAN BUS; Ethernet optional
-
Power Supply: 220V AC (nominal); compatible with 180-250V AC input range
-
Output Performance: Output frequency up to 100Hz; supports precise pulse control
-
Memory Capacity: 300KB program capacity; 200KB data storage capacity
-
Operating Environment: Temperature -10°C to +60°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 180mm × 120mm × 45mm; net weight 0.54kg; DIN rail compatible mounting
-
Protection Features: Overcurrent, overvoltage, undervoltage, overheating protection; encoder fault detection
-
Certifications: CE, RoHS compliant; meets IEC industrial control safety standards
Recommended ABB Related Models
-
ABB KUC321AE HIEE300698R0001: Compact logic control variant, ideal for small-scale packaging line control systems
-
ABB KUC720AE01 3BHB003431R0001: Low-voltage version (24V DC), suitable for mobile robot control in logistics warehouses
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, coordinates with KUC720AE01 for integrated DCS in power plants
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits KUC720AE01’s control data to remote SCADA
-
ABB ACS 580: Low-voltage frequency converter, receives control signals from KUC720AE01 for motor speed regulation
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes KUC720AE01’s operating status and fault alarm information
-
ABB UNITROL 1020: Excitation regulator, pairs with KUC720AE01 for medium-sized generator control
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures 2ms real-time data interaction with KUC720AE01
-
ABB AC500 PLC: Compact controller, works with KUC720AE01 for small-scale automation in food processing lines
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control actions based on KUC720AE01’s commands
-
ABB AI810 3BSE032456R1: 8-channel analog input module, collects field sensor data for KUC720AE01’s control algorithms
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, connects KUC720AE01 to ABB 800xA platform
-
ABB REF620: Digital relay protector, collaborates with KUC720AE01 to safeguard power system equipment
-
ABB MEGATROL: Intelligent excitation solution, integrates with KUC720AE01 for gas turbine generator control
