Introduction to ABB LWN2660-6

LWN2660-6 Product Overview

LWN2660-6 Technical Parameters

• Product Model: LWN2660-6
• Product Type: Power Measurement and Protection Module (LWN Series)
• Core Functions: Real-time power parameter monitoring, energy metering, overcurrent protection, overvoltage protection, undervoltage protection, fault diagnosis and alarm, data communication
• Power Supply: 24V DC input (19.2V-28.8V DC range); Power consumption: ≤5W; Overcurrent and reverse polarity protection
• Measurement Specifications: Voltage measurement range: 0-400V AC (3-phase); Current measurement range: 0-5A AC (direct input), up to 1000A AC with current transformer; Measurement accuracy: Voltage/Current ≤±0.2%, Power/Energy ≤±0.5%; Sampling frequency: 1kHz
• Interface Type: RS485 communication port (supports Modbus RTU protocol); Digital input/output for status monitoring and control; Analog output (4-20mA) for continuous parameter transmission; Plug-in terminals for easy wiring
• Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 2G (10-150Hz); Shock resistance: 15G
• Mechanical & Installation: DIN rail-mounted; Dimensions (approx.): 100mm × 85mm × 45mm; Net weight: approx. 0.3kg; LED indicators for power, operation status, and fault alarms; Flame-retardant housing (UL94 V-0)
• Protection Features: Overcurrent protection (adjustable setting range: 1-10In); Overvoltage protection (105%-120% of rated voltage); Undervoltage protection (80%-95% of rated voltage); Short-circuit protection; Anti-EMI design
• Compatibility: ABB low-voltage circuit breakers, ABB AC500 controllers, other LWN series modules, standard power distribution system components
• Certifications: CE certified; Complies with IEC 61557-1 (power measurement) and IEC 60947-1 (electrical safety) standards; Passes EMC testing
• Applications: Commercial buildings, industrial production facilities, data centers, power distribution stations, renewable energy systems; Low-voltage power distribution monitoring, energy management, electrical equipment protection
