Introduction to ABB LWN2660-6EG 3BHL000986P7002
The ABB LWN2660-6EG (order number: 3BHL000986P7002) is a high-performance dual-output industrial AC-DC power supply, recognized as the “stable energy backbone” for complex automation systems. As a flagship model in ABB’s LWN series, it features two independent 24V DC output channels, specifically designed to power multi-module control systems where isolated power distribution is critical—such as PLC cabinets, sensor networks, and actuator clusters in petrochemical plants and automotive assembly lines. This module stands out with its IP65 protection level, effectively resisting dust intrusion and water splashes in harsh industrial environments, while the advanced EMC performance (compliant with IEC/EN 61000-4 standards) ensures stable operation amid strong electromagnetic interference. Its compact DIN rail-mounted design optimizes cabinet space, and the built-in overload, short-circuit, and over-temperature protection mechanisms safeguard connected equipment, making it a reliable choice for mission-critical applications like process control and industrial robotics.
3BHL000986P7002 Key Technical Specifications
-
Device Type: Dual-output industrial AC-DC switch-mode power supply
-
Input Parameters: 85-264V AC (50/60Hz); wide voltage range for global application
-
Output Configuration: 2 independent channels; each channel 24V DC, 5A; total rated power 247W
-
Conversion Efficiency: Up to 89%, minimizing energy loss and heat generation
-
Communication Protocols: Supports Modbus, PROFIBUS, and Ethernet for remote monitoring and parameter adjustment
-
Protection Features: Output overload (constant current limiting), short-circuit (automatic recovery), over-temperature, and over-voltage protection
-
Operating Environment: Temperature -40°C to +60°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 106mm × 103mm × 138mm; weight ~0.7kg; DIN rail (TS35/7.5) mounting
-
Protection Level: IP65, suitable for dusty and damp on-site environments
-
Cooling Method: Natural convection, no fan design reduces maintenance needs
-
Mechanical Design: PCB with protective coating; aluminum alloy housing for heat dissipation
-
Certifications: CE, RoHS compliant; meets IEC industrial power supply safety standards
Recommended ABB Related Models
-
ABB LWN2660-6E 3BHL000986P7001: Single-output variant (24V DC/10A), cost-effective for single-module control systems in food processing lines
-
ABB LWN2660-6ERG: Enhanced EMC version, ideal for power electronics labs and high-interference welding workshops
-
ABB CP-S.1 24V/40A: High-power single-output switch电源, paired with LWN2660-6EG for large-scale PLC cabinets in power plants
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, core unit powered by LWN2660-6EG in integrated DCS
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, receives stable power from LWN2660-6EG for real-time data transmission
-
ABB TP854 3BSE025349R1: 7-inch HMI, powered by LWN2660-6EG to visualize power supply status and equipment data
-
ABB SD812F 3BDH000014R1: Redundant power module, works with LWN2660-6EG for 24/7 uninterrupted power in petrochemical control systems
-
ABB AI810 3BSE032456R1: 8-channel analog input module, collects sensor data while being powered by LWN2660-6EG
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control commands using power from LWN2660-6EG’s dual channels
-
ABB CP-PX 24V/10A: Compact flat power supply, complements LWN2660-6EG in space-constrained automation boxes
-
ABB ACS 580: Low-voltage frequency converter, receives auxiliary power from LWN2660-6EG for motor control in water treatment
-
ABB AC500 PLC: Programmable logic controller, core control unit paired with LWN2660-6EG in manufacturing lines
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures stable communication with LWN2660-6EG-powered systems
-
ABB PCD237A101 3BHE028915R0101: Distributed I/O module, expands LWN2660-6EG’s power supply range in oilfield pumping stations
