Introduction to ABB O3EId HENF452777R3
HENF452777R3 Product Overview
The ABB O3EId HENF452777R3 is a high-level coded non-contact safety sensor belonging to ABB’s O3EId product series, specifically designed for guard interlocking applications in industrial environments. It serves as a critical safety component to protect operators by monitoring the status of doors, hatches, and other protective guards in machinery and production lines. Featuring advanced non-contact detection technology with a sensing range of 0-15mm, it ensures reliable detection without physical wear, enhancing long-term operational stability. Equipped with OSSD (Output Signal Switching Device) outputs and serial connection capability, up to 30 units can be connected in series to meet large-scale safety system requirements. With a high protection class of IP69K, the sensor withstands high-pressure and high-temperature cleaning, making it suitable for harsh industrial settings such as food processing, automotive manufacturing, and packaging industries.
HENF452777R3 Technical Specifications
-
Product Model: O3EId HENF452777R3
-
Product Type: High-Level Coded Non-Contact Safety Sensor
-
Core Functions: Guard interlocking detection, door/hatch status monitoring, OSSD signal output, serial connection, local reset
-
Detection Technology: Non-contact coded detection; Sensing range: 0-15mm
-
Safety Performance: Complies with EN ISO 14119:2013 standard; Achieves PLe safety level without periodic checks (per ISO/TR 24119)
-
Electrical Specifications: Equipped with OSSD outputs and inputs for serial connection; Supports up to 30 units in series connection
-
Power Supply: 24V DC ±10%; Power consumption ≤5W
-
Protection Class: IP69K (resistant to high-pressure, high-temperature cleaning)
-
Operating Environment: Temperature range: -20°C to +60°C; Humidity: 5-95% (non-condensing); Resistant to vibration and electromagnetic interference
-
Mechanical Dimensions: Compact design; Dimensions: 85mm × 35mm × 25mm; Weight: Approximately 0.1kg
-
Installation Method: Easy mounting with standard brackets; No complex alignment required
-
Certifications: CE certified; Complies with international industrial safety standards
