Introduction to ABB P5EAa HENF206350R2
Product Overview
The ABB P5EAa HENF206350R2 is a high-performance digital control module, specifically engineered for industrial automation and process control applications. As a key component of ABB’s Advant master distributed control system (DCS), it integrates advanced digital control technology and reliable hardware design, enabling precise control of industrial processes such as temperature, pressure, flow, and motion. The module supports Modbus TCP/IP communication protocol, facilitating seamless data exchange and integration with upper-level control systems and other field devices. Featuring a rugged and compact structure, it is designed to withstand harsh industrial environments with extreme temperatures and electromagnetic interference, ensuring long-term stable operation. Widely applied in power generation, petrochemical, metallurgy, and water treatment industries, the P5EAa HENF206350R2 helps users achieve efficient process control, reduce maintenance costs, and enhance overall system reliability.
Technical Specifications
-
Product Model: P5EAa HENF206350R2
-
Product Type: Industrial Digital Control Module
-
Core Functions: PID control mode (configurable setpoint range, proportional band, integral time, derivative time), analog input/output processing, real-time data transmission, fault detection and self-protection, system integration and expansion
-
Power Supply: 24 VDC input; Compatible with 208-600 V AC rated voltage
-
Input/Output Specifications: Supports ±10 V, 0-20 mA analog signals; Output voltage range: 0-10 V DC
-
Current Ratings: Rated current: 400-4000 A; Short-circuit breaking current: 50 kA RMS
-
Communication Interface: Supports Modbus TCP/IP and Ethernet protocols for seamless device integration
-
Control Parameters: Setpoint range: 0-100%; Proportional band: 0-100; Integral time: 0-100 seconds
-
Environmental Ratings: Operating temperature: -40°C to +70°C; Storage temperature: -40°C to +85°C; Protection class: IP30
-
Mechanical & Installation: Compact design (approx. 100×100×50 mm); Weight: approx. 0.5 kg; Easy to install and wire, supporting modular combination
-
Certifications: Complies with industrial automation and process control safety standards
Recommended ABB Same-Series Models
-
ABB P5EAa HENF206351R2: Enhanced digital control module with extended I/O channels, suitable for complex process control scenarios
-
ABB O3EGb HENF315118R2: Industrial control module, supporting multi-protocol communication for diverse system integration
-
ABB INICT01: Infi-Net computer transfer module, facilitating data transmission between INFI 90 DCS and external computers
-
ABB INNIS01: Infi-Net network interface slave module, serving as a key node for Infi-Net communication
-
ABB INPM01: Process monitoring module, enabling real-time collection and analysis of industrial process parameters
-
ABB INCT01: Communication interface module, supporting data exchange between DCS and multiple external devices
-
ABB INLM01: Local control module, realizing localized control and monitoring of on-site equipment
-
ABB INPD01: Process data acquisition module, specialized in high-precision collection of analog and digital signals
-
ABB A44 552-110: Three-phase electricity meter with RS-485, supporting active/reactive energy measurement
-
ABB A44 553-110: Three-phase electricity meter with M-Bus, applicable for 690V systems without additional transformers
-
ABB EM20: Single-phase intelligent power meter, focusing on current and voltage measurement for industrial applications
-
ABB EQ B Series: Standard three-phase electricity meter, direct measurement up to 65A, compatible with CT transformers
