Introduction to ABB PCD230A101 3BHE022291R0101
The ABB PCD230A101 (order number: 3BHE022291R0101) is a versatile distributed I/O module, serving as a critical “data bridge” in industrial control systems. As a key member of ABB’s PCD series for process automation, it specializes in collecting analog and digital signals from on-site devices and transmitting precise control commands to actuators. This module is widely applied in industries such as power generation (turbine auxiliary control), petrochemicals (reaction vessel monitoring), and municipal water treatment (pump station regulation). Its robust design supports hot-swapping for online maintenance, while the galvanic isolation technology ensures stable operation even in high-electromagnetic-interference environments. By seamlessly integrating with ABB’s Symphony Plus and AC 800M control systems, it simplifies system configuration and enhances the reliability of industrial processes.
3BHE022291R0101 Key Technical Specifications
-
Module Type: Distributed mixed-signal I/O module
-
Input Channels: 8 analog input (4-20mA DC / 0-10V DC); 8 digital input (24V DC, dry contact)
-
Output Channels: 4 analog output (4-20mA DC); 4 digital output (24V DC, 2A per channel)
-
Measurement Precision: Analog signals ±0.1% full scale; digital response time ≤1ms
-
Communication Interface: ABB HI Bus; supports IEC 60870-5-104 protocol for remote monitoring
-
Power Supply: 24V DC (18-32V); dual redundant inputs for reliability; power consumption ≤15W
-
Operating Environment: Temperature -20°C to +60°C; humidity 5-95% (non-condensing)
-
Isolation Performance: 2.5kVrms galvanic isolation between channels and power supply
-
Physical Specifications: 100mm × 160mm × 80mm; DIN rail mounting; IP20 protection
-
Installation Feature: Hot-swappable design; compatible with ABB S800 I/O bases
-
Certifications: CE, UL 508, IEC 61131-2, RoHS compliant
-
Diagnostic Function: Real-time channel status monitoring; LED indicators for power, communication and faults
Recommended ABB Related Models
-
ABB PCD231A101 3BHE028911R0101: Digital-focused I/O module (16 digital inputs), ideal for small-scale production lines like food packaging
-
ABB PCD233A101 3BHE028913R0101: Analog-dedicated module (16 analog inputs), suitable for high-precision temperature monitoring in chemical reactors
-
ABB PCD237A101 3BHE028915R0101: High-density mixed I/O module, designed for large power plant boiler control systems
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, perfectly matches PCD230A101 for complex process control
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, enhances PCD230A101’s connectivity with third-party devices
-
ABB AI810 3BSE032456R1: 8-channel analog input module, expands signal collection capacity for multi-station monitoring
-
ABB DO810 3BSE032452R1: 16-channel digital output module, controls multiple actuators in industrial automation lines
-
ABB PCD230A102 3BHE022291R0102: Explosion-proof variant (ATEX Zone 2), used in hazardous areas like oil refineries
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data transmission with PCD230A101
-
ABB PCD221A101 3BHE028921R0101: Low-power I/O module, perfect for remote solar-powered monitoring stations
-
ABB XVC 722 AE101 3BHB002751R0101: Process control module, works with PCD230A101 for precise parameter regulation
-
ABB AC800M 3BSE018105R1: Redundant power supply module, ensures stable power input for PCD230A101 View more …..
