Introduction to ABB PCD235B101 3BHE032025R0101
The ABB PCD235B101 (order number: 3BHE032025R0101) is a high-reliability distributed I/O module, serving as the “field signal gateway” in large-scale industrial automation systems. As a key product in ABB’s PCD series for process control, it specializes in collecting and conditioning analog signals from field sensors (such as temperature, pressure, and flow transmitters) and transmitting standardized data to upper-level controllers. This module is widely applied in power generation (boiler parameter monitoring), petrochemicals (reactor process control), and industrial robotics (sensor data acquisition for ABB robots) . Its robust design features 1500Vrms galvanic isolation between channels, effectively resisting electromagnetic interference from high-power equipment like frequency converters . The compact modular structure supports hot-swapping and seamless integration with ABB’s AC 800M DCS platform, while LED status indicators for each channel simplify on-site fault diagnosis, significantly enhancing the stability of distributed control systems.
3BHE032025R0101 Key Technical Specifications
-
Device Type: Distributed analog input I/O module for industrial process control
-
Input Configuration: 16-channel analog input; supports 4-20mA DC current signals
-
Measurement Accuracy: ±0.05% full scale (FS); ensures precise capture of micro-signal changes
-
Resolution: 24-bit AD conversion; compatible with high-precision sensors
-
Sampling Rate: 50 samples per second per channel; total system sampling rate up to 800 S/s
-
Power Supply: 24V DC (nominal); input range 18-36V DC; typical current consumption 120mA
-
Communication Interface: Integrates with ABB CEX bus; supports real-time data transmission to AC 800M controllers
-
Isolation Performance: 1500Vrms between channels; 1000Vrms between I/O and system
-
Operating Environment: Temperature -20°C to +70°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 124mm × 74mm × 44mm; weight ~0.35kg; 35mm DIN rail mounting
-
Protection Features: Overvoltage protection (up to 30V DC); short-circuit protection; EMC compliant with IEC 61000-4
-
Certifications: CE, RoHS compliant; meets IEC 61131-2 industrial control standards
Recommended ABB Related Models
-
ABB PCD237A101 3BHE028915R0101: 8-channel analog output module, pairs with PCD235B101 for closed-loop control in power plants
-
ABB PCD236B101 3BHE032026R0101: 16-channel digital input module, ideal for sensor signal collection in ABB robot systems
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, core unit processing data from PCD235B101
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits PCD235B101’s data to remote SCADA
-
ABB ACS 580: Low-voltage frequency converter, receives control signals derived from PCD235B101’s sensor data
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes PCD235B101’s measured parameters (temperature, pressure) on-site
-
ABB AI810 3BSE032456R1: 8-channel analog input module, cost-effective alternative for medium-precision applications
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control actions based on PCD235B101’s data
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data interaction with PCD235B101
-
ABB PCD238A101 3BHE032027R0101: 16-channel digital output module, complements PCD235B101 in hybrid signal systems
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, connects PCD235B101 to ABB 800xA platform
-
ABB AC500 PLC: Compact controller, pairs with PCD235B101 for small-scale process control in food processing
-
ABB TB852 3BSC950263R1: Redundant analog output module, enhances PCD235B101’s control reliability in petrochemicals
-
ABB REF620: Digital relay protector, collaborates with PCD235B101 to safeguard power system equipment View more …..
