Introduction to ABB PCD235B1101 3BHE032025R1101
The ABB PCD235B1101 (order number: 3BHE032025R1101) is a high-precision programmable excitation control module, recognized as the “stable operation core” for synchronous generators and industrial drive systems. As a key product in ABB’s PCD (Process Control Device) series, it integrates advanced current regulation algorithms and multi-protocol communication capabilities, specializing in precise control of excitation current to stabilize generator output voltage and optimize energy conversion efficiency. This module plays a critical role in power generation (synchronous generator excitation control), petrochemicals (reactor process drive), and industrial facilities (motor excitation regulation), as well as water treatment and mining equipment control. Its robust industrial-grade design features 1500Vrms galvanic isolation and wide environmental adaptability, enabling stable operation amid temperature fluctuations (-20°C to +70°C) and strong electromagnetic interference from high-voltage equipment.
Key Technical Specifications
-
Device Type: Programmable excitation control module for generator and industrial drive systems
-
Core Function: Precise excitation current regulation; generator output voltage stabilization
-
Control Performance: Excitation current control accuracy ±0.1% FS; response time ≤ 2ms
-
I/O Configuration: 8 analog input channels (4-20mA); 6 analog output channels (4-20mA); 12 digital I/O points
-
Power Supply: 220V AC (nominal); compatible with 115-250V AC input range; typical power consumption ≤ 25W
-
Communication Protocols: Supports Modbus RTU/TCP, PROFIBUS DP, Ethernet/IP; RS-485 and Ethernet interfaces
-
Isolation Performance: 1500Vrms between control circuit and power circuit; 1000Vrms between I/O channels
-
Operating Environment: Temperature -20°C to +70°C; humidity 5-95% (non-condensing); storage temp -40°C to +85°C
-
Physical Specifications: 124mm × 74mm × 44mm; weight ~0.4kg; 35mm DIN rail mounting
-
Protection Features: Overcurrent, overvoltage, undervoltage protection; overtemperature alarm; short-circuit protection
-
Compatibility: Perfectly matches ABB UNITROL 1020 excitation system and AC 800M DCS
-
Certifications: CE, UL compliant; RoHS certified; meets IEC 61131-2 and IEC 60076 industrial standards
Recommended ABB Related Models
-
ABB PCD237A101 3BHE028915R0101: 8-channel analog output module, pairs with PCD235B1101 for closed-loop excitation control in power plants
-
ABB UNITROL 1020: Integrated excitation regulator, core system integrating PCD235B1101 for generator control
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, processes real-time excitation data from PCD235B1101 in integrated DCS
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits PCD235B1101’s data to remote SCADA systems
-
ABB ACS 580: Low-voltage frequency converter, receives control signals derived from PCD235B1101’s excitation data
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes PCD235B1101’s excitation current and voltage parameters on-site
-
ABB AI810 3BSE032456R1: 8-channel analog input module, expands PCD235B1101’s sensor signal collection range
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes emergency shutdown based on PCD235B1101’s fault signals
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures 2ms real-time data interaction with PCD235B1101
-
ABB PCD236B101 3BHE032026R0101: 16-channel digital input module, collects status signals for PCD235B1101 in excitation systems
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, connects PCD235B1101 to ABB 800xA platform
-
ABB AC500 PLC: Compact controller, pairs with PCD235B1101 for small-scale water treatment plant control
-
ABB REF620: Digital relay protector, collaborates with PCD235B1101 to safeguard generator and power grid equipment
-
ABB GVC736BE101 3BHE019719R0101: Gate driver module, complements PCD235B1101 in hybrid power conversion systems View more …..
