Introduction to ABB PM803F 3BDH000530R1
PM803F 3BDH000530R1 Product Overview
The ABB PM803F 3BDH000530R1 is a high-performance core controller module belonging to the ABB AC800F series, specifically engineered for small and medium-sized industrial automation systems. As the “control core” of the automation system, it is responsible for executing complex control logic, processing real-time data from field sensors, and sending precise control commands to actuators. This module features a compact modular design, which is ideal for installation in control cabinets with limited space, while its powerful 32-bit RISC processor ensures fast and efficient data processing to meet the real-time requirements of industrial control. With excellent environmental adaptability and anti-interference performance, it can operate stably in harsh industrial environments such as manufacturing workshops, power systems, and water treatment facilities. Its high compatibility allows seamless integration with various ABB I/O expansion modules and supports multiple industrial communication protocols, providing a reliable and cost-effective control solution for a wide range of industrial automation applications.
PM803F 3BDH000530R1 Technical Specifications
-
Product Model: PM803F 3BDH000530R1
-
Product Type: Core Controller Module (AC800F Series)
-
Core Functions: Complex control logic execution, real-time field data processing, control command output, program storage and management, fault self-diagnosis, multi-protocol communication, I/O expansion management
-
Processor & Memory: 32-bit RISC microprocessor with a main frequency of up to 400 MHz; RAM: 256 MB (battery-backed for data retention); Flash memory: 128 MB (for program storage)
-
Power Supply: 24 V DC ±10% input (18-32 V DC range); Power consumption: Approximately 3 W; Built-in overcurrent, overvoltage and reverse polarity protection circuits
-
Communication Interfaces: 1 x Ethernet port (supports EtherNet/IP, Modbus TCP/IP); 1 x RS-485 serial port (supports Modbus RTU); Compatible with IEC 60870-5-101/104, DNP3, OPC UA protocols
-
Performance Indicators: Maximum support for 256 I/O points; Basic instruction execution time: < 0.2 μs; Supports remote diagnosis and fault detection; Enables on-line program modification and debugging
-
Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 2 G; Shock resistance: 15 G
-
Mechanical & Installation: DIN rail-mounted design; Dimensions (approx.): 70 mm × 100 mm × 65 mm; Weight: approx. 0.2 kg; Pluggable terminals for easy wiring and maintenance; LED status indicators (power, operation, communication, fault)
-
Compatibility: Fully compatible with ABB AC800F series I/O expansion modules; Seamless integration with ABB Advant Controller 800xA system; Supports connection with standard industrial sensors and actuators
-
Certifications & Compliance: CE certified; Complies with relevant industrial control standards; Passes strict EMC (Electromagnetic Compatibility) testing
-
Application Adaptability: Suitable for small and medium-sized automation systems in industries such as manufacturing, power generation, water treatment, and petrochemical; Ideal for production line control, process monitoring, and equipment automation control scenarios
Recommended ABB Same-Series & Related Models
-
ABB PM801F 3BDH000528R1: AC800F series entry-level controller module, cost-effective for simple control scenarios with limited I/O points
-
ABB PM802F 3BDH000529R1: AC800F series standard controller module, balanced performance for medium-scale control systems
-
ABB PM810F 3BDH000531R1: AC800F series high-performance controller module, enhanced processing capability for complex control algorithms
-
ABB PM820F 3BDH000532R1: AC800F series redundant controller module, dual-channel design for safety-critical control systems
-
ABB AI810 3BSE020510R1: AC800F compatible analog input module, 8-channel 4-20mA input for field sensor data acquisition
-
ABB DI810 3BSE020511R1: AC800F compatible digital input module, 16-channel dry contact input for status signal collection
-
ABB AO810 3BSE020512R1: AC800F compatible analog output module, 4-channel 4-20mA output for actuator control
-
ABB DO810 3BSE020513R1: AC800F compatible digital output module, 16-channel transistor output for switching device control
-
ABB CI854A 3BSE030221R1: PROFIBUS communication module, expanding AC800F series’ fieldbus communication capability
-
ABB CI858K01 3BSE018135R1: Industrial Ethernet module, enhancing AC800F series’ Ethernet communication performance
-
ABB PM851AK01 3BSE066485R1: AC800M series compact controller module, compatible with AC800F system for large-scale expansion
-
ABB PM861K01 3BSE018105R1: AC800M series standard controller module, matching AC800F I/O modules for system upgrade
-
ABB PS865 3BSE025266R1: Power supply module, dedicated to providing stable power for AC800F series controller modules
-
ABB PP835A 3BSE042234R2: Process panel, matching AC800F-based systems for local operation and parameter setting
-
ABB TB852 3BSC950263R1: Distributed I/O module, extending AC800F system’s I/O capacity for distributed control scenarios
There are no reviews yet.
