Introduction to ABB PM865K01 3BSE031151R1
PM865K01 3BSE031151R1 Product Overview
The ABB PM865K01 3BSE031151R1 is a high-integrity processor unit belonging to the AC 800M controller series, specifically engineered for safety-critical industrial automation applications. As the core component of the ABB Ability System 800xA, it is responsible for executing complex control logic, real-time data processing, and I/O management, ensuring reliable operation of critical industrial processes. Certified to SIL 2 and SIL 3 standards, the module supports CPU redundancy configuration, which significantly enhances system availability and fault tolerance, making it ideal for safety-critical scenarios such as petrochemical processing, power generation, and chemical manufacturing. Equipped with a 96 MHz MPC862P processor and conformal coating protection, it delivers powerful processing performance while resisting dust, moisture, and vibration in harsh industrial environments.
PM865K01 3BSE031151R1 Technical Specifications
-
Product Model: PM865K01 3BSE031151R1
-
Product Type: High Integrity Processor Unit (AC 800M Controller Series)
-
Core Functions: Complex control logic execution, real-time data processing, I/O management, CPU redundancy support, fault self-diagnosis, status monitoring, safety-critical control
-
Processor & Memory: Processor: 96 MHz MPC862P; RAM: 32 MB (for application execution); Flash: 1 GB (for data storage); Supports CompactFlash card expansion
-
Power Supply: 24 V DC ±20% input; Input current: 1 A; Power consumption: Up to 20 W; Built-in overcurrent protection and voltage stabilization
-
Communication Interfaces: 2 x RJ45 Ethernet ports (for flexible network connectivity); 2 x RS-485 serial ports (for additional communication options); Supports Modbus, PROFIBUS DP, OPC UA protocols
-
Environmental Ratings: Operating temperature: -40°C to +85°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20 (for cabinet installation); Conformal coating for harsh environment resistance
-
Mechanical & Installation: Rail-mounted design; Dimensions (approx.): 80 mm × 130 mm × 220 mm (width × height × depth); Weight: approx. 2.0 kg; LED status indicators (power, operation, fault); Hot-swap supported with compatible accessories
-
Performance Indicators: Deterministic control with VxWorks real-time operating system; MTBF (Mean Time Between Failures): ≥ 100,000 hours; Supports 1000 boolean operations with high efficiency
-
Compatibility: Fully compatible with ABB Ability System 800xA; Seamless integration with ABB S800/S900 I/O modules; Supports CEX-Bus redundancy
-
Certifications & Compliance: SIL 2 and SIL 3 certified (IEC 61508); CE, UL certified; Complies with international industrial safety standards
-
Application Adaptability: Suitable for safety-critical applications in petrochemical, power generation, chemical manufacturing, and discrete manufacturing industries; Ideal for process control, energy management, and real-time monitoring systems
Recommended ABB Same-Series & Related Models
-
ABB PM865K02 3BSE031152R1: Redundant version of PM865 series, with dual CPU configuration for higher system availability
-
ABB PM857K01 3BSE088385R1: AC 800M high integrity controller, SIL 3 certified, single CPU configuration for safety applications
-
ABB PM857K02 3BSE088386R1: Redundant high integrity controller, dual PM857K01 units for safety-critical systems
-
ABB PM863K01 3BSE088381R1: AC 800M safety controller, SIL 3 certified, single CPU for combined process and safety automation
-
ABB PM863K02 3BSE088382R1: Redundant safety controller, dual CPU configuration for enhanced fault tolerance
-
ABB PM866AK01 3BSE076939R1: High-performance AC 800M controller, 133 MHz processor, 64 MB memory for complex applications
-
ABB PM866AK02: Redundant version of PM866A series, supporting large-scale I/O expansion and high-speed data processing
-
ABB PM867K01: AC 800M high integrity controller, SIL 3 certified, 64 MB memory for high-performance safety applications
-
ABB PM867K02: Redundant high integrity controller, dual CPU design for mission-critical safety systems
-
ABB PM891K01: High-performance AC 800M controller, 256 MB memory, 0.043 ms boolean operation speed for large-scale systems
-
ABB PM891K02: Redundant version of PM891 series, supporting high-speed processing for complex automation scenarios
-
ABB PM862K01 3BSE076940R1: AC 800M controller, 32 MB memory, non-redundant for general process automation
-
ABB PM862K02 3BSE081636R1: Redundant PM862 controller, dual CPU for enhanced availability in general automation applications
-
ABB SM812: AC 800M high integrity controller, SIL 3 certified, redundant configuration for safety-critical processes
-
ABB BC810K02: AC 800M accessory module, supporting hot swap for redundant controller systems
