Introduction to ABB PM866-2 3BSE050201R1

3BSE050201R1 PM866-2 Product Overview

3BSE050201R1 PM866-2 Technical Specifications

• Product Model: PM866-2 3BSE050201R1
• Product Type: Redundant Processor Unit (AC800M Series)
• Core Functions: Redundant control operation, seamless fault switchover, complex control task execution, real-time data processing, multi-protocol communication, system status monitoring, fault self-diagnosis
• Processor & Memory: Dual-core industrial processor; 4 GB RAM for program and data storage
• Power Supply: 24 V DC input; Input voltage range: 19.2 V DC to 30 V DC; Power consumption: 15 W; Maximum current consumption: 0.8 A; Built-in overcurrent and overvoltage protection
• Communication Interfaces: Multiple Ethernet ports, serial ports, and USB interfaces; Supports Modbus and other industrial communication protocols; Enables seamless integration with peripheral devices
• Performance Indicators: Fast fault switchover time; Supports complex process control, machine control, and motion control; Enables real-time data logging and remote communication
• Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Shock resistance: 15 G; Vibration resistance: 2 G
• Mechanical & Installation: Rail-mounted modular design; Dimensions (approx.): 100 mm × 140 mm × 60 mm; Weight: approx. 1.2 kg; Plug-in terminals for easy wiring and maintenance; LED status indicators (power, operation, redundancy status, fault)
• Compatibility: Fully compatible with ABB System 800xA; Seamless integration with AC800M series communication modules and I/O modules; Supports connection with standard industrial sensors and actuators
• Certifications & Compliance: CE certified; Complies with relevant industrial control standards; Passes strict EMC (Electromagnetic Compatibility) testing
• Application Adaptability: Suitable for oil and gas, power generation, process manufacturing, and transportation industries; Ideal for mission-critical control systems, DCS excitation systems, and large-scale distributed control scenarios

Recommended ABB Same-Series & Related Models

1. ABB PM866AK01 3BSE076939R1: AC800M series redundant processor unit, basic redundancy configuration for medium-scale critical systems
2. ABB PM866AK02 3BSE081637R1: AC800M series enhanced redundant processor unit, improved processing performance for complex tasks
3. ABB PM867K01 3BSE076355R1: AC800M series high-end redundant processor unit, advanced redundancy management for large-scale systems
4. ABB PM867K02 3BSE081638R1: AC800M series premium redundant processor unit, maximum fault tolerance for ultra-critical applications
5. ABB PM865K01 3BSE031151R1: AC800M series standard processor unit, cost-effective for non-redundant control scenarios
6. ABB PM865K02 3BSE031150R1: AC800M series enhanced standard processor unit, balanced performance for medium-scale systems
7. ABB PM891K01 3BSE053241R1: AC800M series edge computing processor unit, integrates local data processing and cloud communication
8. ABB PM891K02 3BSE053242R1: AC800M series redundant edge computing unit, reliable edge control for distributed systems
9. ABB CI860K01 3BSE032444R1: AC800M series communication module, extends Ethernet communication capabilities
10. ABB CI858K01 3BSE018135R1: AC800M series industrial Ethernet module, enhances high-speed network integration
11. ABB BC810K02 3BSE031155R1: AC800M series interconnection unit, supports redundant system module interconnection
12. ABB BC820K02 3BSE071500R1: AC800M series extension unit, expands system coverage for large-scale layouts
13. ABB SM812K01 3BSE072270R1: AC800M series high-performance processor unit, dedicated for high-demanding control tasks
14. ABB PS865 3BSE025266R1: AC800M series power supply module, provides stable power for redundant processor units
15. ABB PP835A 3BSE042234R2: AC800M series process panel, enables local operation and monitoring for PM866-2 based systems
