Introduction to ABB PM902F 3BDH001000R0005
3BDH001000R0005 Product Overview
The ABB PM902F 3BDH001000R0005 is a core CPU module belonging to ABB’s Freelance AC 900F controller series, serving as the central processing unit for industrial automation systems. Equipped with a high-performance embedded microprocessor, it integrates comprehensive functions including logic control, real-time data processing, and multi-protocol communication, making it suitable for both process control and mechatronic applications. Widely deployed in manufacturing production lines, petrochemical process systems, power plant auxiliary equipment, and robot control platforms, it regulates key production parameters, coordinates the operation of distributed I/O modules, and enables seamless data interaction between field devices and upper-level monitoring systems. Its modular design supports flexible expansion and hot-swapping, while built-in overload, overcurrent, and overheating protection ensures operational safety. With four Ethernet interfaces and multiple serial ports, it is compatible with mainstream industrial protocols such as Modbus TCP, PROFINET IO, and EtherNet/IP, facilitating integration into complex automation networks.
3BDH001000R0005 Technical Specifications
-
Product Model: PM902F (Order Code: 3BDH001000R0005)
-
Product Type: Core CPU module (central processing unit)
-
Series Affiliation: ABB Freelance AC 900F Controller Series
-
Core Functions: Logic control, real-time data processing, multi-protocol communication, fault diagnosis, equipment coordination
-
Processor Configuration: High-performance embedded microprocessor (optimized for industrial control)
-
Memory Capacity: 512MB RAM; 256MB non-volatile Flash memory (for firmware and configuration)
-
Communication Interfaces: 4×Ethernet ports, 2×serial ports (RS-232/485), 1×diagnostic interface
-
Supported Protocols: Modbus TCP, PROFINET IO, EtherNet/IP, CANopen
-
I/O Compatibility: 16 digital inputs (supports NAMUR/PNP/NPN sensors); 8 digital outputs (configurable PNP/NPN, 0.5A per channel)
-
Power Supply: 24VDC (allowable range: 18-30VDC); powered by AC 900F system backplane
-
Operating Environment: Temperature 0°C to +60°C; Humidity 5-95% (non-condensing); IP20 protection rating (when cabinet-mounted)
-
Mechanical Features: DIN rail mount; Hot-swappable design; LED status indicators for power and communication
-
Certifications: CE, UL certified; Compliant with IEC 61131-2 industrial control standards
Recommended ABB Products
-
ABB PM904F 3BDH001001R0005: A high-end CPU module in the same series, with enhanced memory for large-scale control systems.
-
ABB AI835 3BDH000055R1: An analog input module that transmits sensor data to the PM902F for processing.
-
ABB AO835 3BDH000056R1: An analog output module that executes continuous control commands from the PM902F.
-
ABB DI830 3BDH000052R1: A digital input module that collects on-site status signals for the PM902F.
-
ABB DO830 3BDH000053R1: A digital output module that drives field actuators based on the PM902F’s signals.
-
ABB PM864AK01 3BSE018161R1: An AC 800M series CPU that coordinates with the PM902F in hybrid control systems.
-
ABB CI854A 3BSE022363R1: A communication module that expands the PM902F’s Profibus DP connectivity.
-
ABB REF615 1MRK504153-BEN: A protection relay that works with the PM902F to ensure power equipment safety.
-
ABB XO08R2 1SBP260109R1001: A digital output module compatible with the PM902F for extended control capacity.
-
ABB PS860 3BSE008545R1: A redundant power supply module that provides stable power for the PM902F.
