Introduction to ABB PP825A 3BSE042240R3
PP825A 3BSE042240R3 Product Overview
The ABB PP825A 3BSE042240R3 is a standard touchscreen Human-Machine Interface (HMI) belonging to the ABB Panel 800 series, specifically designed for intuitive operation and real-time monitoring in industrial automation systems. As a critical interaction component between operators and control systems, it provides a user-friendly graphical interface for parameter configuration, process status monitoring, fault diagnosis, and operational control. Equipped with a 5.7-inch color resistive touchscreen, the HMI delivers clear and vivid display effects, supporting intuitive gesture operations such as sliding and tapping to enhance operational efficiency. With an IP65 protection rating, it can resist dust and water splashes in harsh industrial environments, making it widely applicable in manufacturing, energy, chemical, food and beverage processing industries. Its high compatibility allows seamless integration with ABB AC800 series controllers and other automation equipment, enabling stable data exchange and collaborative work to ensure the smooth operation of industrial production processes.
PP825A 3BSE042240R3 Technical Specifications
-
Product Model: PP825A 3BSE042240R3
-
Product Type: Standard Touchscreen Human-Machine Interface (HMI) (Panel 800 Series)
-
Core Functions: Intuitive human-machine interaction, process status real-time monitoring, parameter configuration, fault diagnosis & alarm, multi-language support, data logging & display
-
Display Specifications: Screen size: 5.7 inches; Display type: Color LCD; Resolution: 320 × 240 pixels; Touchscreen type: Resistive; Brightness: 250 cd/m²; Contrast ratio: 500:1; Viewing angle: 70° (left/right) and 70° (up/down); Response time: 10 ms
-
Power Supply: 24 V DC ±10% input (18-32 V DC range); Power consumption: Low energy design; Built-in overvoltage and overcurrent protection circuits
-
Communication Interfaces: Supports RS-232, RS-485 serial communication and Ethernet interface; Compatible with Modbus RTU/TCP, OPC UA and other industrial communication protocols; Enables stable data exchange with upper-level controllers and field devices
-
Environmental Ratings: Operating temperature: -20°C to +55°C; Storage temperature: -25°C to +65°C; Relative humidity: 0%-95% (non-condensing); Protection class: IP65; Strong anti-electromagnetic interference capability
-
Mechanical & Installation: Compact modular design; Dimensions (approx.): 204 mm × 143 mm × 50 mm; Weight: approx. 0.4 kg; Panel-mounted installation; Die-cast powder-coated aluminum housing for durability; Easy maintenance with detachable components
-
Performance Indicators: Supports multi-language interface switching; Based on vector high-resolution graphics with icon-based navigation; MTBF (Mean Time Between Failures): ≥ 100,000 hours; Supports custom interface design and function configuration
-
Compatibility: Fully compatible with ABB AC800 series controllers; Seamless integration with ABB Panel 800 series accessories; Supports connection with third-party automation equipment via standard communication protocols
-
Certifications & Compliance: CE certified; Complies with international industrial HMI standards; Passes strict EMC (Electromagnetic Compatibility) and environmental durability testing
-
Application Adaptability: Suitable for operation and monitoring in industrial automation systems such as manufacturing production lines, energy management systems, chemical process control, and food and beverage processing; Ideal for scenarios requiring intuitive human-machine interaction and real-time process supervision
