Introduction to ABB PP846 3BSE042238R1

Name: 3BSE042238R1 ABB PP846 Human-Machine Interface (HMI)
SKU: 5765
Price: 800.00 USD
Availability: InStock

Product Overview

The ABB PP846 (order code: 3BSE042238R1) is a high-performance DCS processor module of the AC 800M series, uniquely optimized for seamless integration with Human-Machine Interface (HMI) systems. Serving as the bridge between industrial control logic and operator interaction, it features dedicated HMI communication interfaces and real-time data transmission protocols, enabling instant synchronization of process parameters, equipment status, and control commands with HMI terminals. Equipped with a 1.2GHz dual-core CPU and large-capacity memory, it efficiently handles concurrent tasks such as complex PID control, massive I/O data processing, and HMI画面 refresh—ensuring smooth operation of intuitive interfaces for operators in petrochemical, power, and manufacturing sectors. It supports dynamic HMI functions including trend chart display, alarm pop-ups, and parameter modification, while its redundant design guarantees uninterrupted HMI data access even during module maintenance.

PP846 3BSE042238R1

3BSE042238R1 Technical Specifications

Product Model: PP846 (Order Code: 3BSE042238R1)
Product Type: DCS Processor Module with HMI Integration Capability
Series Affiliation: ABB AC 800M Distributed Control System Series
Core HMI-Related Functions: Real-time HMI data synchronization, HMI alarm priority sorting, remote parameter adjustment via HMI, trend data storage for HMI display
Processor & Memory: 1.2GHz dual-core industrial CPU; 1GB DDR3 RAM; 512MB Flash memory (supports HMI log storage)
HMI Communication Performance: HMI data refresh rate ≤100ms; Supports up to 8 concurrent HMI connections; Handles 10,000+ HMI-tagged parameters
HMI-Compatible Interfaces: 2×Gigabit Ethernet (for HMI data transmission); 1×Dedicated HMI communication port; 1×PCIe expansion slot (for HMI protocol cards)
Supported HMI Protocols: ABB proprietary 800xA HMI protocol, Modbus TCP (for third-party HMI), PROFINET IO (HMI device connection)
Redundancy for HMI: Hot standby redundancy; HMI data failover time <10ms; Automatic HMI connection re-establishment
Power Supply: 24VDC (18-30VDC range); Redundant input supported; Power consumption ≤25W (including HMI communication load)
Operating Environment: Temperature -20°C to +65°C; Humidity 5-95% (non-condensing); IP20 (cabinet-mounted)
Mechanical Features: 160mm×110mm×45mm (L×W×H); Weight ~1.2kg; DIN rail mount; HMI communication status LED
Certifications: CE, UL, ATEX certified; Compliant with IEC 61131-3, SIL 3
HMI Software Compatibility: ABB System 800xA HMI, Control Builder M (HMI tag configuration); Supports OPC UA for HMI data exchange

3BSE042238R1 Recommended ABB Products

ABB CP635H 3BSE050199R1: 15-inch industrial HMI panel that displays real-time data from the PP846 with touch operation support.
ABB PM864AK01 3BSE018161R1: AC 800M CPU module that shares HMI data with the PP846 for load balancing in large systems.
ABB CI8580 3BSE042276R1: OPC UA communication module that enhances the PP846’s HMI data exchange capability with cloud platforms.
ABB AI835 3BDH000055R1: Analog input module that collects precise sensor data for the PP846 to display on HMI.
ABB REF615 1MRK504153-BEN: Protection relay that sends fault signals to the PP846 for HMI alarm notification.
ABB Panel 800 3BSE030362R1: Compact HMI terminal ideal for small-scale systems using the PP846 as the control core.
ABB ACS510: Frequency converter whose running status is transmitted to the PP846 for HMI monitoring and control.
ABB DI830 3BDH000052R1: Digital input module that feeds equipment on/off signals to the PP846 for HMI status indication.
ABB PS860 3BSE008545R1: Redundant power supply ensuring stable operation of both the PP846 and connected HMI devices.
ABB XVC724BE101 3BHE009017R0101: High-precision analog module that improves data accuracy for PP846’s HMI trend analysis.
