Introduction to ABB PP846 3BSE042238R1
PP846 3BSE042238R1 Product Overview
The ABB PP846 3BSE042238R1 is a high-performance processor unit under the AC 800M controller series, specifically designed for large-scale and complex industrial automation applications. As a core computing component of the ABB Ability System 800xA, it is responsible for executing advanced control logic, processing massive real-time industrial data, and managing multiple I/O modules simultaneously. Equipped with a powerful multi-core processor and large-capacity memory, the module delivers exceptional computing performance, enabling efficient handling of complex control tasks in process automation, discrete manufacturing, and energy management systems. It supports redundant configuration, which greatly enhances system availability and fault tolerance, making it suitable for critical industrial scenarios such as petrochemical plants, power stations, and large-scale manufacturing facilities. With a compact modular design and comprehensive communication capabilities, it seamlessly integrates with ABB S800/S900 I/O modules and various industrial networks, providing a reliable and high-performance control solution for large-scale automation systems.
PP846 3BSE042238R1 Technical Specifications
-
Product Model: PP846 3BSE042238R1
-
Product Type: High-Performance Processor Unit (AC 800M Controller Series)
-
Core Functions: Complex control logic execution, massive real-time data processing, multi-I/O module management, CPU redundancy support, fault self-diagnosis, status monitoring, advanced algorithm operation
-
Processor & Memory: Processor: Multi-core industrial-grade processor; RAM: 2 GB (for application execution); Flash: 4 GB (for data storage); Supports CompactFlash and SD card expansion
-
Power Supply: 24 V DC ±20% input; Input current: 1.5 A; Power consumption: Up to 35 W; Built-in overcurrent, overvoltage protection and voltage stabilization circuit
-
Communication Interfaces: 4 x RJ45 Ethernet ports (10/100/1000 Mbps); 2 x RS-485 serial ports; Supports PROFIBUS DP, Modbus TCP/RTU, OPC UA, Ethernet/IP protocols; Supports CEX-Bus and PCIe expansion
-
Environmental Ratings: Operating temperature: -40°C to +85°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20 (for cabinet installation); Conformal coating for harsh environment resistance
-
Mechanical & Installation: Rail-mounted design; Dimensions (approx.): 80 mm × 130 mm × 220 mm (width × height × depth); Weight: approx. 2.5 kg; LED status indicators (power, operation, fault, redundancy); Hot-swap supported
-
Performance Indicators: Deterministic control with VxWorks real-time operating system; Boolean operation speed: 0.02 ms per operation; Supports up to 10,000 I/O points; MTBF (Mean Time Between Failures): ≥ 150,000 hours
-
Compatibility: Fully compatible with ABB Ability System 800xA; Seamless integration with ABB S800/S900 I/O modules; Supports integration with third-party industrial devices via standard protocols
-
Certifications & Compliance: CE, UL, ATEX certified; Complies with IEC 61508 (SIL 2) standards; Passes strict EMC (Electromagnetic Compatibility) and vibration testing
-
Application Adaptability: Suitable for large-scale and complex automation applications in petrochemical, power generation, metallurgy, and discrete manufacturing industries; Ideal for process control, energy management, and integrated automation systems
Recommended ABB Same-Series & Related Models
-
ABB PP845 3BSE042237R1: AC 800M mid-range processor unit, single-core processor with 1 GB RAM for medium-scale automation systems
-
ABB PP847 3BSE042239R1: AC 800M high-end processor unit, octa-core processor with 4 GB RAM for ultra-large-scale automation scenarios
-
ABB PM865K01 3BSE031151R1: AC 800M high integrity controller, SIL 3 certified for safety-critical applications
-
ABB PM866AK01 3BSE076939R1: AC 800M high-performance controller, 133 MHz processor with 64 MB memory for complex control tasks
-
ABB PM891K01: AC 800M high-performance controller, 256 MB memory with 0.043 ms boolean operation speed
-
ABB PP835 3BSE036914R1: AC 800M compact processor unit, cost-effective for small to medium-scale automation applications
-
ABB PP836 3BSE036915R1: AC 800M enhanced compact controller, supporting redundant configuration for medium-scale systems
-
ABB PM862K01 3BSE076940R1: AC 800M basic controller, 32 MB memory for general process automation
-
ABB PM863K01 3BSE088381R1: AC 800M safety controller, SIL 3 certified for combined process and safety automation
-
ABB SM812: AC 800M high integrity controller, redundant configuration for safety-critical processes
-
ABB CI854A 3BSE030150R1: AC 800M PROFIBUS communication module, enabling data exchange between controller and field devices
-
ABB CI867K01: AC 800M Industrial Ethernet module, supporting PROFINET for seamless DCS integration
-
ABB BC810K02: AC 800M accessory module, supporting hot swap for redundant controller systems
-
ABB PP820 3BSE022496R1: AC 800M entry-level processor unit, cost-effective for small-scale automation applications
-
ABB PM857K01 3BSE088385R1: AC 800M high integrity controller, single CPU configuration for safety applications
