Introduction to ABB PPC902AE101 3BHE010751R0101
3BHE010751R0101 Product Overview
The ABB PPC902AE101 (order code: 3BHE010751R0101) is a high-integration digital input/output (I/O) module belonging to ABB’s Ability™ System 800xA and AC500 PLC product ecosystems. Equipped with a 1GHz ARM Cortex-A9 dual-core processor, it integrates 32-channel digital input and 32-channel digital output functions, along with 4 high-speed counter interfaces, making it ideal for high-density signal acquisition and real-time control tasks. Widely applied in discrete manufacturing (production lines, robots), process industries (petrochemical, energy), and machine control systems, it collects status signals from sensors, drives actuators like solenoid valves and motors, and enables precise speed monitoring via high-speed counters. Its compact design and Modbus RTU communication capability ensure seamless integration with upper-level controllers, while built-in short-circuit and temperature protection enhances operational reliability in harsh industrial environments.
3BHE010751R0101 Technical Specifications
-
Product Model: PPC902AE101 (Order Code: 3BHE010751R0101)
-
Product Type: High-integration digital input/output (I/O) module
-
Series Affiliation: ABB Ability™ System 800xA / AC500 PLC Series
-
Core Functions: Digital signal acquisition, field device control, high-speed counting, fault protection, data communication
-
Processor Configuration: ARM Cortex-A9 dual-core, 1GHz
-
Memory Capacity: 1GB DDR3 RAM; 4GB eMMC ROM; SD card slot for expansion
-
I/O Configuration: 32 digital inputs (24VDC); 32 digital outputs (24VDC); 4 high-speed counters (max 100kHz)
-
I/O Performance: Input current ≤7mA; Output current ≤500mA per channel; Response time ≤1ms (input/output)
-
Communication Interface: RS485; 2×Ethernet ports; 1×USB; 1×RS-232
-
Supported Protocols: Modbus RTU; Profibus DP; Ethernet-compatible protocols
-
Power Supply: 24VDC (allowable range: 0-30VDC); Power consumption ≤6W
-
Operating Environment: Temperature -25°C to +70°C; Humidity 5-95% (non-condensing); IP20 protection rating (cabinet-mounted)
-
Mechanical Features: 130mm×35mm×130mm (L×W×H); Weight ~0.3kg; DIN rail mount; LED status indicators per channel
-
Certifications: CE, UL certified; Compliant with industrial control safety standards
Recommended ABB Products
-
ABB PM902F 3BDH001000R0005: A core CPU module that processes the I/O data collected by the PPC902AE101 for control decisions.
-
ABB AI835 3BDH000055R1: An analog input module that complements the PPC902AE101 by acquiring continuous sensor signals.
-
ABB AO835 3BDH000056R1: An analog output module that works with the PPC902AE101 for mixed-signal control systems.
-
ABB CI854A 3BSE022363R1: A communication module that expands the PPC902AE101’s Profibus DP connectivity.
-
ABB PM864AK01 3BSE018161R1: An AC 800M series CPU that coordinates with the PPC902AE101 in hybrid automation systems.
-
ABB DI830 3BDH000052R1: A dedicated digital input module that extends the PPC902AE101’s signal acquisition capacity.
-
ABB DO830 3BDH000053R1: A high-reliability digital output module that complements the PPC902AE101 for heavy-load control.
-
ABB REF615 1MRK504153-BEN: A protection relay that uses the PPC902AE101’s signals to ensure power equipment safety.
-
ABB XO08R2 1SBP260109R1001: A compact digital output module compatible with the PPC902AE101 for space-constrained applications.
-
ABB PS860 3BSE008545R1: A redundant power supply module that provides stable 24VDC power for the PPC902AE101.
