Introduction to ABB REF542PLUS 1VCF752000

REF542PLUS 1VCF752000 Product Overview

REF542PLUS 1VCF752000 Technical Parameters

• Product Model: REF542PLUS 1VCF752000
• Product Type: Numerical Relay Protection and Control Device (REF Series)
• Core Functions: Comprehensive overcurrent/earth fault protection, differential protection, overload protection, fault location, real-time power measurement, remote control, event logging, fault diagnosis
• Power Supply: DC supply: 24V/48V/110V/220V DC (±20% fluctuation); AC supply: 110V/220V AC (±15% fluctuation); Power consumption: ≤25W
• Protection Specifications: Current range: 0.1-20In; Voltage range: 0-120V (phase); Frequency range: 45-65Hz; Operating time: ≤20ms (fast trip); Accuracy class: 0.5S (measurement), 5P10 (protection)
• Interface Type: Ethernet (IEC 61850, Modbus TCP/IP); RS485 (Modbus RTU); Digital I/O: 16 inputs/8 outputs (configurable); Analog inputs: 8 channels (for voltage/current measurement); Relay outputs: 8 NO/NC contacts
• Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 1G (10-150Hz); Shock resistance: 10G
• Mechanical & Installation: Panel-mounted; Dimensions (approx.): 270×230×150mm; Net weight: approx. 3.8kg; LCD display (128×64 pixels); LED status indicators; IP54 protection rating
• Protection Features: Adjustable protection settings; Fault wave recording; Anti-tampering function; Self-monitoring and alarm; Overvoltage/undervoltage protection
• Compatibility: ABB MicroSCADA Pro, System 800xA DCS, other REF series relays, standard power system sensors (CT/PT)
• Certifications: CE certified; Complies with IEC 60255, IEC 61850, IEC 61010 standards; Passes EMC and electrical safety testing
• Applications: Medium-voltage power distribution networks, power transformers, feeders, motors, industrial plants, commercial buildings, utility power grids; Power system protection, control, and monitoring

Recommended ABB Same-Series Models

1. ABB REF541PLUS 1VCF751000: Feeder protection specialized, integrated auto-reclosing function
2. ABB REF543PLUS 1VCF753000: Transformer protection focused, enhanced differential protection algorithm
3. ABB REF545PLUS 1VCF755000: Motor protection dedicated, thermal overload protection with curve selection
4. ABB REF550PLUS 1VCF756000: Busbar protection, high-speed fault clearing for busbar systems
5. ABB REF615 1VCF801000: Advanced feeder protection, IEC 61850-9-2LE process bus compatible
6. ABB REF615R 1VCF801100: Feeder protection with arc flash detection, enhanced safety for personnel
7. ABB REF620 1VCF802000: Transformer protection, integrated tap changer control
8. ABB REF620R 1VCF802100: Transformer protection with redundant communication, high reliability for critical transformers
9. ABB REF630 1VCF803000: Motor protection, predictive maintenance functions for motor health monitoring
10. ABB REF640 1VCF804000: Busbar protection, modular design for easy expansion
11. ABB REF650 1VCF805000: Universal protection relay, flexible configuration for multiple applications
12. ABB REF670 1VCF806000: Line differential protection, suitable for long-distance transmission lines
13. ABB REF670R 1VCF806100: Line differential protection with redundant power supply, high availability
14. ABB REF810 1VCF810000: Substation automation relay, integrated bay control functions
15. ABB REF820 1VCF820000: Advanced substation protection, support for synchrophasor measurement
