Introduction to ABB SCYC51020 58052582G

SCYC51020 58052582G Product Overview

SCYC51020 58052582G Technical Specifications

• Product Model: SCYC51020 58052582G
• Product Type: Signal Processing & Control Module (Industrial Automation Series)
• Core Functions: Analog & digital signal conversion, signal filtering & conditioning, anti-electromagnetic interference, real-time signal transmission, fault self-diagnosis, status monitoring
• Signal Specifications: Analog input range: 4-20 mA DC / 0-10 V DC; Analog output range: 4-20 mA DC / 0-10 V DC (selectable); Digital input/output: 8-channel digital input, 8-channel digital output; Signal conversion accuracy: ±0.1% FS
• Power Supply: 24 V DC ±10% input; Power consumption: ≤ 8 W (full load); Built-in voltage stabilization and surge protection
• Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20
• Mechanical & Installation: DIN rail-mounted design; Dimensions (approx.): 140 mm × 100 mm × 50 mm; Weight: approx. 0.6 kg; Pluggable terminals for easy maintenance; LED status indicators (power, operation, fault)
• Performance Indicators: Signal processing speed: ≤ 1 ms; Response time: < 50 μs; MTBF (Mean Time Between Failures): ≥ 100,000 hours; Anti-interference capability: Complies with IEC 61000-4 standards
• Compatibility: Fully compatible with ABB AC800 series controllers, S800 I/O modules, and DCS systems; Supports Modbus, PROFIBUS and other industrial communication protocols
• Certifications & Compliance: CE, UL certified; Complies with IEC 61131-2 industrial control standards; Passes strict EMC (Electromagnetic Compatibility) testing
• Application Adaptability: Suitable for signal processing and control in industrial automation systems such as power plant auxiliary equipment control, petrochemical process monitoring, and manufacturing production line control; Ideal for connecting sensors, actuators, and upper-level controllers

Recommended ABB Same-Series & Related Models

1. ABB SCYC51030 58052583G: Enhanced signal processing module with 16-channel digital I/O, suitable for large-scale signal acquisition scenarios
2. ABB 216DC61 HESG324064R100: Digital input module, specialized in high-speed acquisition of switch and sensor signals
3. ABB 216DA61 HESG324065R100: Analog input module, supporting 4-20 mA/0-10 V signal acquisition with high precision
4. ABB 216EA61b: Analog output module, providing 8-channel stable analog signals for industrial actuators
5. ABB CI854A 3BSE030150R1: PROFIBUS communication module, enabling data exchange between controller and field devices
6. ABB AC800M PM851: Modular controller, supporting basic logic operations and small-scale I/O expansion for industrial control
7. ABB 216VC62A HESG324442R13/C: Voltage control module, for voltage signal monitoring, regulation and protection
8. ABB 216DD61: Digital I/O module, integrating 16 digital inputs and 16 digital outputs
9. ABB 216AE61: Temperature input module, supporting PT100/K-type thermocouple signal acquisition
10. ABB 216CA61: Communication interface module, enabling 216 series modules to connect with Ethernet networks
11. ABB 216ED61: Analog I/O combination module, with 4 analog inputs and 4 analog outputs
12. ABB SCYC51010 58052581G: Entry-level signal processing module, with 4-channel analog I/O for small-scale control systems
13. ABB 216AB61 HESG324013R100: Protective relay module, for generator/transformer differential and overcurrent protection
14. ABB S800 I/O AI835: High-precision analog input module, with 16-bit resolution for sensitive signal acquisition
15. ABB CI867K01: Industrial Ethernet module, supporting PROFINET for seamless DCS system integration
