Introduction to ABB TP858 3BSE018138R1
TP858 3BSE018138R1 Product Overview
The ABB TP858 3BSE018138R1 is a dedicated baseboard module designed for ABB Distributed Digital Control System (DCS). Serving as a critical mounting and connection platform, it provides stable physical support and signal transmission channels for interface modules such as CI858K01 and CI872K01. Its modular design simplifies installation and integration into various industrial automation systems, while the fully sealed PCB protection process and advanced software-hardware filtering technology ensure excellent anti-interference performance and reliability. Widely applied in power generation, petrochemical, metallurgy and other industrial fields, this baseboard module enables efficient and stable operation of the entire control system by facilitating seamless communication between interface modules and other system components.
TP858 3BSE018138R1 Technical Parameters
-
Product Model: TP858 3BSE018138R1
-
Product Type: DDCS Interface Module Baseboard
-
Core Functions: Provides physical support and signal connection for interface modules, enables high-speed data transmission, supports multi-protocol communication, integrates circuit protection functions
-
Power Supply: 24 V DC input
-
Interface Compatibility: Compatible with CI858K01, CI872K01 and other ABB interface modules; supports Ethernet, serial port and analog I/O interfaces
-
Communication Protocols: Supports Ethernet/IP, Modbus TCP/IP and other industrial communication protocols
-
Environmental Ratings: Operating temperature: -40°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20
-
Mechanical & Installation: DIN rail mounting; Dimensions (approx.): 120 mm × 80 mm × 40 mm; Net weight: approx. 0.5 kg; Modular design for easy maintenance and replacement
-
Protection Features: Equipped with overvoltage, overcurrent and overtemperature protection; Adopts software-hardware filtering technology to enhance anti-interference capability
-
Compatibility: Fully compatible with ABB DDCS; Seamless integration with ABB industrial automation system components
-
Certifications & Compliance: CE certified; Complies with relevant industrial automation standards
-
Application Adaptability: Suitable for nuclear power plants, thermal power plants, wind farms, petrochemical plants and metallurgical automation production lines
Recommended ABB Same-Series Models
-
ABB TP858 3BSE018138R2: Revised version of TP858 baseboard, with optimized circuit design for improved stability
-
ABB CI858K01 3BSE018135R1: DriveBus interface module, works with TP858 for high-speed data exchange in DDCS
-
ABB CI872K01 3BSE042246R1: Serial communication interface module, extends TP858-based system’s serial communication capability
-
ABB TP857 3BSE018137R1: Compact DDCS interface baseboard, suitable for space-constrained installation scenarios
-
ABB CI854A 3BSE030221R1: PROFIBUS communication module, compatible with TP858 for fieldbus integration
-
ABB TP860 3BSE018140R1: High-performance DDCS baseboard, supports redundant connection for safety-critical systems
-
ABB CI858K02 3BSE076698R1: Enhanced DriveBus interface module, matches TP858 for large-data-volume transmission
-
ABB TP859 3BSE018139R1: Specialized baseboard for harsh environments, with enhanced protection performance
-
ABB CI867K01 3BSE046837R1: Ethernet/IP interface module, enables TP858-based systems to connect to Ethernet/IP networks
-
ABB TP856 3BSE018136R1: Entry-level DDCS interface baseboard, cost-effective for basic control system applications
-
ABB CI853A 3BSE028100R1: Modbus RTU communication module, expands TP858’s communication protocol support
-
ABB TP861 3BSE018141R1: Redundant baseboard module, dual-channel design for high-reliability control systems
-
ABB CI852A 3BSE026986R1: CANopen communication module, works with TP858 for industrial bus communication
-
ABB TP855 3BSE018135R1: Compact baseboard with integrated signal conditioning, suitable for small-scale automation systems
-
ABB CI851A 3BSE026985R1: Profinet communication module, enhances TP858-based system’s network connectivity
