Introduction to ABB UAD142A01 3BHE012551R0001
UAD142A01 3BHE012551R0001 Product Overview
The ABB UAD142A01 3BHE012551R0001 is a high-reliability extended output power board designed specifically for ABB distributed control systems (DCS). As a key power supply expansion component, it converts 24V DC input power into multiple output channels, providing stable and reliable power support for various connected devices such as modules, sensors, and actuators in industrial automation systems. Its robust structural design enables it to withstand harsh industrial conditions including high temperatures, humidity, and vibration, ensuring continuous operation in critical environments. With easy installation and configuration features, it seamlessly integrates with ABB Advant Master DCS and other automation components, widely serving power generation, oil and gas, chemical processing, and other industrial fields to guarantee the stable and efficient operation of the entire control system.
UAD142A01 3BHE012551R0001 Technical Parameters
-
Product Model: UAD142A01 3BHE012551R0001
-
Product Type: Extended Output Power Board (UAD Series)
-
Core Functions: Converts 24V DC input to multi-channel output, provides expanded power supply capability, supports system communication integration, built-in fault diagnosis, overcurrent/overvoltage protection
-
Power Supply: Input voltage: 24V DC; Multi-channel DC output (configurable for different load requirements)
-
Interface Compatibility: Equipped with standard industrial communication interfaces; Supports connection with ABB DCS modules, sensors, and actuators
-
Communication Protocols: Supports Modbus, PROFIBUS, and Ethernet protocols for seamless system integration
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: Compliant with industrial standards
-
Mechanical & Installation: DIN rail or panel mounting; Dimensions (approx.): 150 mm × 100 mm × 45 mm; Net weight: approx. 0.6 kg; Plug-in terminals for easy wiring and maintenance
-
Protection Features: Integrated overcurrent, overvoltage, and undervoltage protection; Built-in diagnostic system for fault detection and reporting
-
Compatibility: Fully compatible with ABB Advant Master DCS; Seamless integration with ABB industrial automation components
-
Certifications & Compliance: CE certified; Complies with relevant industrial automation and power supply standards
-
Application Adaptability: Suitable for power generation, oil and gas, chemical processing, urban rail transit, and industrial manufacturing; Ideal for process control, discrete control, data acquisition, and remote monitoring systems
