Introduction to ABB UFC719AE01 3BHB003041R0101

Name: 3BHB003041R0101 UFC719AE01 ABB 3BHB00072R0101
SKU: 5719
Price: 1169.00 USD
Availability: InStock

3BHB003041R0101 Product Overview

The ABB UFC719AE01 (order code: 3BHB003041R0101) is a core I/O rack controller/communication processor specifically engineered for ABB’s AC 800M and Ability™ System 800xA distributed control systems (DCS). Serving as the “brain” of remote I/O stations, it manages up to 16 connected I/O modules (analog/digital) via a proprietary high-speed backplane, aggregates field data, and enables seamless communication with central controllers. Widely deployed in power plants, refineries, and water treatment facilities, it solves the challenges of long-distance signal transmission by centralizing on-site I/O devices, reducing cable costs and electromagnetic interference. Equipped with hardware redundancy and hot-swappable capability, it ensures millisecond-level failover to avoid data loss, while supporting multiple industrial protocols to integrate with both ABB proprietary and third-party systems. Its rugged design withstands harsh industrial environments, making it a reliable cornerstone for distributed automation architectures.

UFC719AE01

3BHB003041R0101 Technical Specifications

Product Model: UFC719AE01 (Order Code: 3BHB003041R0101)
Product Type: Remote I/O rack main control board / communication processor
Series Affiliation: ABB AC 800M / Ability™ System 800xA DCS Series
Core Functions: I/O module management, data aggregation, fieldbus communication, redundancy control, hot-swapping
Managed I/O Capacity: Up to 16 analog/digital I/O modules per rack
Communication Interfaces: 1×Profibus-DP (master/slave configurable), 1×RS485 (Modbus RTU), optional fiber/Ethernet port
Supported Protocols: Profibus-DP (12Mbps max), Modbus RTU/ASCII, ABB Advant Fieldbus
Data Latency: ≤10ms for critical signal transmission
Power Supply: 24VDC nominal (19.2-30VDC range); Redundant input supported; Power consumption 5-7W
Operating Environment: Temperature -20°C to +60°C; Humidity 5-95% (non-condensing); Port-to-port isolation 1500VAC
Mechanical Features: 120mm×180mm×200mm (L×W×H); Weight ~0.5kg; Plug-in rack mount; LED status indicators
Certifications: CE, UL, CSA certified; Compliant with IEC 61000-6-2/4, IEC 61131-2 standards
Redundancy: Dual-board hot standby support; Automatic failover within milliseconds
