Introduction to ABB UFC721AE101 3BHB002916R0101
3BHB002916R0101 Product Overview
The ABB UFC721AE101 (order code: 3BHB002916R0101) is a highly integrated universal I/O module designed for ABB’s Ability™ System 800xA and AC 800M distributed control systems (DCS). It combines 8 analog input channels, 4 analog output channels, 16 digital input channels, and 8 digital output channels in a single unit, equipped with a 32-bit RISC processor to handle mixed signal processing efficiently. Widely used in petrochemical, power generation, and manufacturing industries, it integrates data from temperature, pressure, and level sensors, drives valves and pumps via output signals, and provides real-time status feedback for centralized control. Its advanced signal isolation technology prevents interference between analog and digital signals, while the hot-swappable design allows for maintenance without system shutdown. Compatible with PROFINET, Modbus TCP, and Profibus DP protocols, it seamlessly connects to upper-level controllers and monitoring systems, enhancing the flexibility and scalability of automation networks.
3BHB002916R0101 Technical Specifications
-
Product Model: UFC721AE101 (Order Code: 3BHB002916R0101)
-
Product Type: High-integration universal I/O module (mixed analog-digital)
-
Series Affiliation: ABB Ability™ System 800xA / AC 800M DCS Series
-
Core Functions: Mixed signal acquisition/control, real-time data processing, fault diagnosis, anti-interference protection
-
Processor Configuration: 32-bit RISC processor, 200MHz
-
I/O Configuration: 8 analog inputs, 4 analog outputs, 16 digital inputs, 8 digital outputs
-
Analog Signal Types: Input: 4-20mA DC, 0-10V DC, RTD (PT100); Output: 4-20mA DC, 0-10V DC
-
Digital Signal Specifications: Input: 24VDC (PNP/NPN); Output: 24VDC (0.5A per channel)
-
Measurement Accuracy: Analog input: ±0.05% FS; Analog output: ±0.1% FS
-
Communication Interface: 2×Ethernet ports, 1×Profibus DP port
-
Power Supply: 24VDC (18-30VDC range); Redundant input supported; Power consumption ≤12W
-
Operating Environment: Temperature -25°C to +70°C; Humidity 5-95% (non-condensing); IP20 (cabinet-mounted)
-
Mechanical Features: 160mm×120mm×45mm (L×W×H); Weight ~0.8kg; DIN rail mount; LED indicators per channel
-
Certifications: CE, UL, ATEX certified; Compliant with IEC 61131-2, SIL 2 standards
Recommended ABB Products
-
ABB UFC722AE101 3BHB002917R0101: A higher-channel universal I/O module with 16 analog inputs, ideal for large-scale signal integration.
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU module that processes mixed signals collected by the UFC721AE101.
-
ABB XVC724BE101 3BHE009017R0101: High-precision analog input module that expands the UFC721AE101’s measurement capability.
-
ABB CI854A 3BSE022363R1: Communication module that extends the UFC721AE101’s Profibus DP network coverage.
-
ABB REF615 1MRK504153-BEN: Protection relay that uses the UFC721AE101’s signals to trigger over-limit safety actions.
-
ABB PPC902AE101 3BHE010751R0101: Digital I/O module that complements the UFC721AE101 for high-density digital control.
-
ABB AO835 3BDH000056R1: High-performance analog output module that enhances the UFC721AE101’s control precision.
-
ABB PM902F 3BDH001000R0005: Freelance series CPU that integrates the UFC721AE101’s data in hybrid control systems.
-
ABB XO08R2 1SBP260109R1001: Compact digital output module that extends the UFC721AE101’s driving capacity.
-
ABB PS860 3BSE008545R1: Redundant power supply module that ensures stable operation of the UFC721AE101.
