Introduction to ABB UFC762AE101 3BHE006412R0101
The ABB UFC762AE101 (order number: 3BHE006412R0101) is a high-precision analog input module, recognized as the “signal acquisition cornerstone” for ABB AC 800M DCS and industrial automation systems. As a key product in ABB’s UFC series, it integrates high-accuracy signal conversion and multi-channel parallel acquisition capabilities, specializing in collecting and processing analog signals from on-site transmitters (such as temperature, pressure, and flow sensors) and transmitting standardized data to upper-level controllers. This module is widely applied in scenarios like petrochemical reactor monitoring, power plant steam parameter collection, and pharmaceutical process control, perfectly matching ABB AC 800M controllers and Symphony®Plus distributed control systems. Its robust industrial-grade design features 1500Vrms galvanic isolation between channels, effectively resisting electromagnetic interference from industrial environments, while the built-in signal filtering function ensures stable data output even with signal fluctuations.
3BHE006412R0101 Key Technical Specifications
-
Device Type: High-precision analog input module for industrial measurement and control systems
-
Core Functions: Analog signal acquisition, signal filtering, A/D conversion, isolated data transmission
-
Compatible Controllers: ABB AC 800M series (PM866/PM864), Symphony®Plus DCS, AC500 PLC
-
Channel Configuration: 16 differential analog input channels; supports 4-20mA, 0-20mA, 0-10V signal types
-
Measurement Performance: Signal accuracy ±0.05% FS; sampling rate 100Hz per channel; conversion time ≤ 1ms
-
Power Supply: 24V DC (nominal); input range 18-36V DC; typical power consumption ≤ 12W
-
Communication Interface: ABB CEX-Bus; supports hot-swapping; data transmission rate up to 10Mbps
-
Isolation Performance: 1500Vrms between channels; 2000Vrms between I/O and system; 1000Vrms between power and signal
-
Operating Environment: Temperature -20°C to +70°C; humidity 5-95% (non-condensing); storage temp -40°C to +85°C
-
Physical Specifications: 120mm × 75mm × 40mm; weight ~0.3kg; 35mm DIN rail mounting
-
Protection Features: Overvoltage protection (up to 30V DC); short-circuit protection; EMC compliant with IEC 61000-4
-
Certifications: CE, UL, RoHS compliant; meets IEC 61131-2 industrial control standards; ATEX Zone 2 certified
Recommended ABB Related Models
-
ABB UFC765AE102 3BHE003604R0102: 8-channel high-speed analog input module, ideal for real-time pressure monitoring in petrochemical reactors
-
ABB UFC760BE143 3BHE004573R0143: Analog output module, pairs with UFC762AE101 for closed-loop control in power plant steam systems
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, core unit processing data from UFC762AE101
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits UFC762AE101’s data to remote SCADA
-
ABB AI810 3BSE032456R1: 8-channel analog input module, cost-effective alternative for medium-precision applications
-
ABB AO810 3BSE032453R1: 8-channel analog output module, executes control actions based on UFC762AE101’s data
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes UFC762AE101’s measured parameters (temperature, flow) on-site
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data interaction with UFC762AE101
-
ABB XVC769AE101: Digital I/O expansion module, complements UFC762AE101 in hybrid signal systems
-
ABB PCD235B1101 3BHE032025R1101: Excitation control module, integrates UFC762AE101’s data for generator parameter regulation
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, connects UFC762AE101 to ABB 800xA platform
-
ABB AC500 PLC: Compact controller, pairs with UFC762AE101 for small-scale process control in food processing
-
ABB REF620: Digital relay protector, collaborates with UFC762AE101 to safeguard power system equipment
-
ABB ACS 580: Low-voltage frequency converter, receives control signals derived from UFC762AE101’s sensor data
-
ABB BC810: CEX-Bus interconnection unit, enhances UFC762AE101’s communication bus reliability View more …..
