Introduction to ABB UFC911B106 3BHE037864R0106
3BHE037864R0106 Product Overview
The ABB UFC911B106 (order code: 3BHE037864R0106) is a high-performance hybrid signal control module under ABB’s UFC (Universal Function Controller) series, engineered for industrial automation, motor control, and process monitoring scenarios. Integrating 16 digital input channels, 16 digital output channels, and built-in vector control algorithms, it specializes in precise speed and torque regulation of AC motors, while supporting real-time acquisition of sensor signals for closed-loop control. Widely applied in manufacturing production lines, robot control systems, power equipment management, and building automation (HVAC, lighting), it optimizes energy efficiency by 15-20% compared to traditional control modules and ensures stable operation of mechanical equipment. Equipped with multi-layer protection functions (overcurrent, overvoltage, temperature protection, I2t current limiting), it effectively avoids damage from abnormal working conditions. Compatible with Modbus TCP/IP, Profibus, and CAN bus protocols, it seamlessly connects to ABB’s AC 800M DCS and third-party control platforms, facilitating centralized management and data analysis.
3BHE037864R0106 Technical Specifications
-
Product Model: UFC911B106 (Order Code: 3BHE037864R0106)
-
Product Type: High-performance hybrid signal control module
-
Series Affiliation: ABB UFC Universal Function Controller Series
-
Core Functions: AC motor vector control, mixed signal acquisition/processing, over-limit protection, multi-protocol communication
-
I/O Configuration: 16 digital inputs (24VDC), 16 digital outputs (24VDC, 0.5A per channel)
-
Motor Control Performance: Supports 0-2000rpm speed range; Torque regulation range 0-5.8Nm; Control accuracy ±0.1%
-
Rated Parameters: Adaptable to 380V AC motor; Matching motor power up to 7.5kW; Input current 19.7A
-
Protection Features: Overcurrent, overvoltage, undervoltage, temperature protection, I2t current limiting
-
Communication Interface: 1×Ethernet port, 2×RS485 ports, 1×CAN bus port
-
Supported Protocols: Modbus TCP/IP, Profibus DP, CANopen, Ethernet/IP
-
Power Supply: 24VDC ±20% (redundant input supported); Output power 20W
-
Operating Environment: Temperature -20°C to +70°C; Humidity 5-95% (non-condensing); IP20 protection rating
-
Mechanical Features: 350mm×210mm×140mm (L×W×H); Weight ~3kg; DIN rail mount; LED status indicators
-
Certifications: CE, UL certified; Compliant with IEC 61131-3 industrial control standards
