Introduction to ABB UNITROL 1020 3BHE030579R0003

UNITROL 1020 3BHE030579R0003 Product Overview

UNITROL 1020 3BHE030579R0003 Technical Parameters

• Product Model: UNITROL 1020 3BHE030579R0003
• Product Type: Static Excitation Regulator (UNITROL Series)
• Core Functions: Automatic Voltage Regulation (AVR), Manual Current Regulation (MCR), constant power factor control, excitation limit protection, fault diagnosis & alarm, seamless control mode switching
• Power Supply: 24V DC control power (19.2V-28.8V DC); 3-phase 380V AC (±10%) for rectifier unit; Power consumption: ≤30W (control unit)
• Control Specifications: Voltage regulation accuracy: ≤±0.5% of rated value; Response time: ≤20ms; Excitation magnification: 1.6-2.5 times (adjustable); Voltage adjustment range: 15%-120% of rated terminal voltage
• Interface Type: 4-20mA analog I/O for sensors and control commands; Digital I/O for status monitoring and interlocking; RS485 port (supports Modbus RTU); Backplane interface for ABB automation system integration
• Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 2G (10-150Hz); Shock resistance: 15G
• Mechanical & Installation: DIN rail or panel mountable; Dimensions (approx.): 180mm × 250mm × 100mm; Net weight: approx. 2.5kg; Plug-in terminals for easy wiring; LED indicators for power, operation status and faults
• Protection Features: Over-excitation protection, under-excitation limit, over-voltage protection, rotor over-current protection, loss-of-field protection, PT disconnection protection, anti-EMI design, flame-retardant housing
• Compatibility: ABB System 800xA DCS, 1MW-50MW synchronous generators, ABB UNITROL auxiliary modules, standard industrial sensors and actuators
• Certifications: CE certified; Complies with IEC 61000-6-2 (EMC) and IEC 60034-1; Passes strict industrial safety and performance tests
• Applications: Thermal power plants, hydropower plants, wind power plants, industrial cogeneration systems, diesel generator sets; Synchronous generator excitation control, power quality regulation, grid stability enhancement
