Introduction to ABB XO08R2 1SBP260109R1001
Product Overview
The ABB XO08R2 1SBP260109R1001 is a high-performance distributed digital output module, specifically designed for ABB’s AC 800M and Symphony Plus control systems. It serves as a critical interface between central controllers and field actuators, providing reliable switching and control capabilities for industrial processes. Engineered to deliver stable output signals for valves, pumps, and other executive components, this module is widely applied in power generation, petrochemical, and water treatment industries, ensuring precise execution of control commands even in harsh industrial environments. Its modular design supports hot-swapping, minimizing downtime during maintenance, while built-in diagnostic functions enable real-time monitoring of output status and fault alerts. Fully compatible with ABB’s control platforms, it communicates via the proprietary PROFINET or Profibus protocols, facilitating seamless integration into large-scale distributed control systems (DCS) for centralized management and control.
XO08R2 Technical Specifications
-
Product Model: XO08R2 (Order Code: 1SBP260109R1001)
-
Product Type: Distributed digital output module
-
Series Affiliation: ABB AC 800M/Symphony Plus Compatible
-
Core Functions: Digital signal output, field device control, hot-swapping support, real-time fault diagnosis
-
Output Channels: 8 channels, individually configurable
-
Output Type: Relay output, NO (Normally Open) contact
-
Load Capacity: 2A per channel, 10A total per module (resistive load)
-
Voltage Compatibility: 24VDC, 110VAC, 230VAC
-
Communication Protocol: PROFINET, Profibus DP
-
Power Supply: 24VDC (redundant power input supported)
-
Operating Environment: Temperature -20°C to +60°C; Humidity 5-95% (non-condensing); IP20 protection rating (when installed in cabinet)
-
Mechanical Features: DIN rail mount; Hot-swappable design; LED status indicators per channel
-
Certifications: CE, UL, IEC 61131-2 compliant; SIL 2 safety certified
XO08R2 Recommended ABB Products
-
ABB XI08D 1SBP260108R1001: A digital input module that pairs with the XO08R2 for comprehensive signal collection and output control.
-
ABB AI810 1SBP260105R1001: An analog input module that complements the output module by providing precise sensor data acquisition.
-
ABB AO810 1SBP260106R1001: An analog output module that works with the XO08R2 for mixed signal control in complex industrial processes.
-
ABB AC 800M Controller: The core controller that manages the XO08R2 module and coordinates distributed I/O operations.
-
ABB REF615 1MRK504153-BEN: A protection relay that integrates with the module to ensure safe operation of field equipment.
-
ABB Symphony Plus CM400: A communication module that extends the XO08R2’s connectivity to multiple protocols.
-
ABB XO16R2 1SBP260110R1001: A 16-channel digital output module that expands output capacity for large-scale systems.
-
ABB DI810 1SBP260103R1001: A high-density digital input module that pairs with the XO08R2 for balanced I/O configuration.
-
ABB PM861 1SBP260100R1001: A processor module that serves as the control core for systems using the XO08R2 module.
-
ABB DO810 1SBP260104R1001: A compact digital output module that complements the XO08R2 in space-constrained applications.
