Introduction to ABB XVC 722 AE101 3BHB002751R0101

The ABB XVC 722 AE101 (order number: 3BHB002751R0101) is a high-precision industrial control module, specifically engineered for process control and monitoring in medium-voltage power systems. As a key component of ABB’s Symphony Plus and Advant OCS control platforms, it functions as a “signal processor” that collects, converts, and transmits critical operational data between field devices and central controllers. This module is widely applied in industries such as power generation (turbine control), petrochemicals (reaction process regulation), and metallurgy (steel rolling speed control), thanks to its stable signal processing capability and strong anti-interference performance. Its compact design allows easy integration into existing control cabinets, while the modular structure simplifies maintenance—greatly reducing downtime in industrial production.

3BHB002751R0101 Key Technical Specifications

• Module Type: Industrial process control signal module
• Input Channels: 8 analog input channels (4-20mA DC / 0-10V DC), 4 digital input channels (dry contact)
• Output Channels: 4 analog output channels (4-20mA DC), 4 relay output channels (2A/250V AC)
• Signal Resolution: 16-bit for analog signals; ±0.1% full-scale accuracy
• Communication Interface: ABB HI Bus / PROFINET; transmission rate up to 100 Mbps
• Power Supply: 24V DC (18-32V); power consumption ≤ 12W
• Operating Environment: Temperature -20°C to +60°C; humidity 5-95% (non-condensing)
• Protection Features: Overvoltage, overcurrent, and short-circuit protection; galvanic isolation (2.5kVrms)
• Physical Dimensions: 100mm × 160mm × 80mm; DIN rail mounting
• Response Time: ≤ 1ms for digital signals; ≤ 5ms for analog signals
• Certifications: CE, UL, IEC 61131-2, RoHS compliant

Recommended ABB Related Models

1. ABB XVC 721 AE101 3BHB002750R0101: Compact variant of XVC 722 series, 4 analog input/output channels, suitable for small-scale control systems like food processing lines
2. ABB XVC 723 AE101 3BHB002752R0101: High-density control module, 16 analog channels, ideal for large power plant boiler control systems
3. ABB CI854A 3BSE022469R1: PROFIBUS communication module, seamlessly connects XVC series modules to ABB AC 800M controllers
4. ABB PM866 3BSE050200R1: AC 800M CPU controller, perfect matching XVC 722 for complex process control in petrochemical plants
5. ABB XVC 730 AE101: High-temperature resistant control module (-40°C to +70°C), designed for metallurgical and steel mill environments
6. ABB AI810 3BSE032456R1: 8-channel analog input module, alternative for independent high-precision signal collection in water treatment
7. ABB DO810 3BSE032452R1: 16-channel digital output module, expands XVC 722’s control capacity for industrial automation lines
8. ABB XVC 722 AE102 3BHB002751R0102: Explosion-proof version (ATEX Zone 2), used in hazardous areas like chemical storage and refinery units
9. ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data transmission between XVC 722 and remote I/O stations
10. ABB PCD237A101 3BHE028915R0101: Distributed I/O module, compatible with XVC 722 for remote monitoring in oilfield pumping systems
11. ABB XVC 710 AE101: Cost-effective basic control module, suitable for municipal water supply and sewage treatment plants
12. ABB CI853K01 3BSE018103R1: Dual serial communication module, enables XVC 722 to connect with legacy instruments in old industrial sites  View more …..
